LE (ALE)
–5–
ASCTB194E 201610-T
3) PCB side four terminals
2. PCB type
SAFETY STANDARDS
*1. Certified by UL/C-UL, CSA, TÜV and VDE (TMP type)
*2. Certified by UL/C-UL, CSA and VDE (PCB type)
Product
name
UL/C-UL CSA VDE TÜV TV rating CQC
File No. Contact rating Cycles File No. Contact rating File No. Contact rating File No. Contact rating Cycles File No.
Contact
rating
File No. Contact rating Temp.
LE E43149
16A 277V AC 10
5
LR26550
16A 277V AC
4009159
16A 250V AC
(cos
φ
=1.0)
B 12 06
13461 325
16A 250V AC
(cos
φ
=1.0)
10
4
UL: E43149 TV-5
CQC09002039708
16A 250V AC 85°C
185°F
16A 30 DC 10
5
16A 30 DC 16A 30V AC
(0ms)
16A 30V DC
(0ms)
10
4
CSA: LR26550 TV-5
––
18A 125V AC 6000 18A 125V AC – – – – – – –
External dimensions
6.0
0.5
4.75
2.45
1.0 1.0
1.8
3.5
0.50.4
24.9
28.6
20.0
3.5
6.35
8.5
7.5
12.4
#187 terminal
0.8
0.8
.236
.020
.187
.096
.039 .039
.071
.138
.020.016
.980
1.126
.787
.138
.250
.335
.295
.488
.031
.031
PC board pattern (Bottom view)
Tolerance: ±0.1 ±.004
Schematic (Bottom view)
20.0 3.5
4-1.3 dia.
7.5
.787 .138
.051 dia.
.295
CAD Data
Dimension:
Less than 1mm .039inch:
Min. 1mm .039inch
less than 3mm .118 inch:
Min. 3mm .118 inch:
Tolerance
±0.1 ±.004
±0.2 ±.008
±0.3 ±.012
(No tab terminals)
External dimensions
0.5 1.0
2.45
1.0
3.5
0.3
0.4
1.8
4.3
24.9
0.8
0.8
20.0
28.6
7.5
12.4
.020 .039
.096
.039
.138
.012
.016
.071
.169
.980
.031
.031
.787
1.126
.295
.488
PC board pattern (Bottom view)
Tolerance: ±0.1 ±.004
Schematic (Bottom view)
3.5
4-1.3 dia.
20.0
7.5
.138
4-.051 dia.
.787
.295
CAD Data
Dimension:
Less than 1mm .039inch:
Min. 1mm .039inch
less than 3mm .118 inch:
Min. 3mm .118 inch:
Tolerance
±0.1 ±.004
±0.2 ±.008
±0.3 ±.012
