AT24C256W-10SU-2.7数据手册
Page:
of 23 Go
若手册格式错乱，请下载阅览PDF原文件
Atmel-8818C-SEEPROM-AT24C128C-256C-Auto-Datasheet_072016
Features
2-Wire Serial Interface Compatible with I
2
C
Internally Organized 16,384 x 8 (128K), 32,768 x 8 (256K)
Low-voltage, Medium-voltage and High-voltage Operation
Grade 1, V
CC
= 2.5V to 5.5V
Grade 2
(1)
and 3, V
CC
= 1.7V to 5.5V
Extended Temperature Range (Grade 1, 2
(1)
, and 3 as defined in AEC-Q100)
Grade 1 Temperature Range: -40C to 125C
Grade 2 Temperature Range
(1)
: -40C to 105C
Grade 3 Temperature Range: -40
C to 85C
Schmitt Trigger, Filtered Inputs for Noise Suppression
Bidirectional Data Transfer Protocol
400kHz Compatibility
Write Protect Pin for hardware data protection
64 byte Page Write Modes
Partial Page Writes are Allowed
Self-timed Write Cycle (5ms max)
High-reliability
Endurance: 1,000,000 Write Cycles
Data Retention: 100 Years
8-lead JEDEC SOIC, 8-lead TSSOP, and 8-pad UDFN Packages
Note: 1. Contact Sales for Grade 2 Availability
Description
The Atmel
®
AT24C128C/256C provides 131,072/262,144 bits of Serial Electrically
Erasable and Programmable Read-Only Memory (EEPROM) organized as
16,384/32,768 words of 8 bits each. The device is optimized for use in many
automotive applications where low-power and low-voltage operation are essential.
AT24C128C/256C is available in space-saving 8-lead JEDEC SOIC, 8-lead
TSSOP, and 8-pad UDFN packages and is accessed via a 2-wire serial interface.
This device operates from 2.5V to 5.5V for Grade 1 or 1.7V to 5.5V for Grades 2
(1)
and 3.
AT24C128C and AT24C256C
I
2
C Automotive Temperature Serial EEPROM
128K (16,384 x 8), 256K (32,768 x 8)
DATASHEET
