Derating 1
The test voltage of these products is less than 150% of the rated
voltage in the Durability / Operational Life Test.
*Usually MLCC used with derating. So even this kind of products,
special derating have not set specially.
Please refer to below links for details
For general purpose
Only for mobile devices
For automotive
Derating 2
When the product temperature exceeds 105°C, please use this
product within the voltage and temperature derated conditions in
the figure below.
Derating 4
When the product temperature exceeds 125°C, please use this
product within the voltage and temperature derated conditions in
the figure below.
Derating 3
Please apply the derating curve according to the operating
temperature.
Please refer to detailed specifications sheet for details.
Derating 5
When the product temperature exceeds 150°C, please use this
product within the voltage and temperature derated conditions in
the figure below.
Derating 6
When the product temperature exceeds 105°C, please use this
product within the voltage and temperature derated conditions in
the figure below.
Mobile application specific MLCC
These MLCC products are designed for use in devices with a typical
lifetime of less than 5 years.
(Examples: Cellular phone, Smartphone, Tablet PC, Digital camera,
Watch, Electronics dictionary, Small-scale server, IPC-9592B class1
equipment, etc. )
These MLCC products are designed so that the useful lifetime can be
extended longer than 5 years under the following conditions:
[80% of the rated voltage or less, Maximum operating temperature
-20 degree C or less]
Extended useful lifetime, under specific operating conditions, can be
estimated from the following chart.
F?#$3**'$#2'+#'12'+#5&#,!3+3*2'4#$'*30#02#
becomes 1%.
F?*#1#,-2#2&22#$3**'$#2'+#"2'1$-00#$#0#,!#-,*7
and not guaranteed.
F?$7-3&4#,7/3#12'-,1A.*#1#$##*$0##2-!-,2!231@
Lifetime of MLCC can also be estimated from voltage acceleration
and temperature acceleration factors.
Please refer to following URL about these lifetime estimation.
Ceramic Capacitors FAQ
"Are there any methods for estimating the lifetime of a capacitor? "
0255075100125150
0
Product Temperature (°C)
Useful lifetime for mobile application specific MLCC
Rated Voltage (V)
400
500
100
200
300
600
700
Rated Voltage 630V
Rated Voltage 450V
(350V)
(450V)
-75 -50 -25 0 25 50 75 100 125 150 175
0
Product Temperature (°C)
Operating Voltage/Rated Voltage (%)
120
100
80
60
40
20
(50)
Explanation of Symbols in This Catalog
Useful Lifetime (Year)
Product Temperature (°C)
85°C Type 105°C Type
at rated voltage x 80%
0.1
1
10
100
40 50 60 70 80 90 100 110 120 130
10
100
-75 -50 -25 0 25 50 75 100 125 150 175 200
Derating rate of the rated voltage (%)
Product Temperature (°C)
50
25
Temp. Char.: CCG, Rated Voltage: 100V, Capacitance: 100pF-1000pF
Temp. Char.: CCG, Rated Voltage: 100V, Capacitance: 1200pF-3300pF
Temp. Char.: UNJ, Rated Voltage: 200V/500V
Temp. Char.: X9Q, Rated Voltage: 100V
Rated Voltage 1250V
Rated Voltage 1000V
Rated Voltage 630V
0
200
400
600
800
1000
1200
1400
-55 -25 0 25 50 75 100 125 150
Product Temperature (°C)
Rated Voltage/Operating Voltage (V)
C02E.pdf
Jan. 18,2021
!
Note
• Please read rating and
!
CAUTION (for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
4
