3 Device Comparison
Table 3-1 summarizes the available family members.
Table 3-1. Family Members
(1)(2)
USCI
FLASH SRAM ADC12_A
CHANNEL A: CHANNEL B:
DEVICE Timer_A
(3)
Timer_B
(4)
I/O PACKAGE
(KB) (KB) (Ch)
UART, IrDA, SPI, I
2
C
SPI
100 PZ,
MSP430F5438A 256 16 5, 3 7 4 4 14 ext, 2 int 87
113 ZQW
MSP430F5437A 256 16 5, 3 7 2 2 14 ext, 2 int 67 80 PN
100 PZ,
MSP430F5436A 192 16 5, 3 7 4 4 14 ext, 2 int 87
113 ZQW
MSP430F5435A 192 16 5, 3 7 2 2 14 ext, 2 int 67 80 PN
100 PZ,
MSP430F5419A 128 16 5, 3 7 4 4 14 ext, 2 int 87
113 ZQW
MSP430F5418A 128 16 5, 3 7 2 2 14 ext, 2 int 67 80 PN
(1) For the most current part, package, and ordering information, see the Package Option Addendum in Section 8, or see the TI website at
www.ti.com.
(2) Package drawings, thermal data, and symbolization are available at www.ti.com/packaging.
(3) Each number in the sequence represents an instantiation of Timer_A with its associated number of capture compare registers and PWM
output generators available. For example, a number sequence of 3, 5 would represent two instantiations of Timer_A, the first
instantiation having 3 and the second instantiation having 5 capture compare registers and PWM output generators, respectively.
(4) Each number in the sequence represents an instantiation of Timer_B with its associated number of capture compare registers and PWM
output generators available. For example, a number sequence of 3, 5 would represent two instantiations of Timer_B, the first
instantiation having 3 and the second instantiation having 5 capture compare registers and PWM output generators.
6 Device Comparison Copyright © 2010–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: MSP430F5438A MSP430F5437A MSP430F5436A MSP430F5435A MSP430F5419A
MSP430F5418A
