Programming the User-Programmable Machine (UPM) for SDRAM Memory Devices, Rev. 0
6 Freescale Semiconductor
SDRAM Usage
2.1 SDRAM Commands
Table 2 describes the SDRAM commands used with eLBC devices.
2.2 SDRAM Access Cycles
This section includes the following subsections:
• Section 2.2.1, “Initialization”
• Section 2.2.2, “Mode Register Setting”
Table 2. SDRAM Commands
Command Description
A[0:9]
SD
,
A11
SD
A10
SD
CS RAS CAS WE
ACTIVATE Bank activate command. Row addresses are latched on A[0:10]
SD
.
A further command cannot be issued until t
RCD
is met.
V
1
1
Valid address
VLLHH
PRECHARGE
ALL
Precharge all. Precharges both banks simultaneously, then switches
to the idle state. A further command cannot be issued until t
RP
is met.
X
2
2
No effect
HLLHL
WRITE Write. Performs a write access to the bank selected by bank select
(BS
SD
). The data is latched on the positive edge of CLK. The burst
length and the addressing mode are programmed in the mode
register at power-up before the write operation.
V
1
LLHLL
WRITEA Write with autoprecharge (AP). Performs a write command with a
precharge operation automatically after the write operation. This
command cannot be interrupted by any other command. A further
command cannot be issued until t
RP
is met.
V
1
HLHLL
READ Read. Performs a read access to the bank selected by BS. The data
is issued on the positive edge of CLK at a time defined by the CAS
latency.
V
1
LLHLH
READA Read with autoprecharge (AP). Performs a READ command with a
precharge operation automatically after the write operation. This
command cannot be interrupted by any other command. A further
command cannot be issued until t
RP
is met.
V
1
HLHLH
MRS Mode register set. Programs CAS latency, addressing mode, and
burst length in the mode register, which must be configured after
power-up because after reset, the mode register is undefined. A
further command cannot be issued until t
RSC
is met.
V
1
V
1
LL LL
NOP No-operation. Performs no operation (the same as device deselect). X
2
X
2
LH HH
AUTOREFRESH Autorefresh. Refreshes the row address provided by the internal
refresh counter. A further command cannot be issued until t
RC
is met.
X
2
X
2
LL LH
