Applications
Overcurrent protection for telecom applications
Suitable for line card applications e.g. POTS, access networks,
customer premises equipment (CPE) or integrated voice data (IVD)
Features
Compliant with ITU-T standards
basic-level lightning surges (10/700 µs)
basic-level power induction (600 V, 1 A, 0.2 s)
power contact criteria A/B (230 V, 15 min.)
Suitable for continuous connection to mains voltages of 110/230 V AC
in tripped (high-ohmic) condition
Matching available with narrow resistance tolerance
Tight resistance matching maintained after switching
Negligible resistance drift after soldering or switching
Marked with manufacturer's logo, type designation and date code
RoHS-compatible
Options
Alternative tolerances and resistances on request
Delivery mode
Cardboard tape, 360-mm reel, taping to IEC 60286-2 or untaped on cardboard strips
General technical data
Max. operating voltage V
max
245 V AC
Operating temperature range (V = 0) T
op
20/+125 °C
Operating temperature range (V = 230 V) T
op
0/+70 °C
Overcurrent protection for telecom
Leaded disks
Page 2 of 13Please read Cautions and warnings and
Important notes at the end of this document.
