CC3100
SWAS031D –JUNE 2013–REVISED FEBRUARY 2015
CC3100 SimpleLink™ Wi-Fi
®
Network Processor,
Internet-of-Things Solution for MCU Applications
1 Device Overview
1.1 Features
1
– RX Sensitivity
• CC3100 SimpleLink Wi-Fi Consists of Wi-Fi
Network Processor and Power-Management
• –95.7 dBm @ 1 DSSS
Subsystems
• –74.0 dBm @ 54 OFDM
• Wi-Fi CERTIFIED™ Chip
– Application Throughput
• Wi-Fi Network Processor Subsystem
• UDP: 16 Mbps
– Featuring Wi-Fi Internet-On-a-Chip™
• TCP: 13 Mbps
– Dedicated ARM MCU
• Host Interface
Completely Offloads Wi-Fi and Internet
– Interfaces with 8-, 16-, and 32-Bit MCU or
Protocols from the External Microcontroller
ASICs Over SPI or UART Interface
– Wi-Fi Driver and Multiple Internet Protocols in
– Low External Host Driver Footprint: Less Than
ROM
7KB of Code Memory and 700 B of RAM
– 802.11 b/g/n Radio, Baseband, and Medium
Memory Required for TCP Client Application
Access Control (MAC), Wi-Fi Driver, and
• Power-Management Subsystem
Supplicant
– Integrated DC-DC Supports a Wide Range of
– TCP/IP Stack
Supply Voltage:
• Industry-Standard BSD Socket Application
• V
BAT
Wide-Voltage Mode: 2.1 to 3.6 V
Programming Interfaces (APIs)
• Preregulated 1.85-V Mode
• 8 Simultaneous TCP or UDP Sockets
– Advanced Low-Power Modes
• 2 Simultaneous TLS and SSL Sockets
• Hibernate with RTC: 4 µA
– Powerful Crypto Engine for Fast, Secure Wi-Fi
• Low-Power Deep Sleep (LPDS): 115 µA
and Internet Connections with 256-Bit AES
• RX Traffic (MCU Active): 53 mA @
Encryption for TLS and SSL Connections
54 OFDM
– Station, AP, and Wi-Fi Direct
®
Modes
• TX Traffic (MCU Active): 223 mA @
– WPA2 Personal and Enterprise Security
54 OFDM, Maximum Power
– SimpleLink Connection Manager for
• Idle Connected: 690 µA @ DTIM = 1
Autonomous and Fast Wi-Fi Connections
• Clock Source
– SmartConfig™ Technology, AP Mode, and
– 40.0-MHz Crystal with Internal Oscillator
WPS2 for Easy and Flexible Wi-Fi Provisioning
– 32.768-kHz Crystal or External RTC Clock
– TX Power
• Package and Operating Temperature
• 18.0 dBm @ 1 DSSS
– 0.5-mm Pitch, 64-Pin, 9-mm × 9-mm QFN
• 14.5 dBm @ 54 OFDM
– Ambient Temperature Range: –40°C to 85°C
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
