Smartcard reader hardware connection AN2646 - Application note
6/43
2 Smartcard reader hardware connection
To interface to the smartcard, the ST8024 device was used. The ST8024 is a complete low-
cost, analog interface for asynchronous 3 V and 5 V smartcards. It is placed between the
smartcard and the STM8S20x with few external components to perform all supply protection
and control functions.
The M74HC4052 multiplexer/demultiplexer is configured by software to allow the
UART1_TX to the Smartcard_IO
Table 2. STM8S20x and smartcard connection
STM8S20x pins Smartcard pins Function
UART1_CK: PA6 C3: CLK Smartcard clock: output push-pull
UART1_TX: PA5 C7: IO IO serial data: output open drain
PG5 C2: RST Reset to card: output push-pull
PG7 C1: V
CC
Supply voltage: output push-pull
PE0 OFF Smartcard detect: input floating
PG4 3/5V 3 V or 5 V: output push-pull
