2 Ordering information scheme
Figure 12. BTA and BTB series
Figure 13. T25 series
Table 6. Product Selector
Part Numbers
Voltage (xxx)
Sensitivity Type Package
600 V 800 V
BTA24-xxxBRG X X 50 mA Standard TO-220AB
BTA/BTB
(1)
24-xxxBWRG
1. BTB: non insulated TO-220AB package
X X 50 mA Snubberless TO-220AB
BTA/BTB
(1)
24-xxxCWRG X X 35 mA Snubberless TO-220AB
BTA25-xxxBRG X X 50 mA Standard RD91
BTA25-xxxBWRG X X 50 mA Snubberless RD91
BTA25-xxxCWRG X X 35 mA Snubberless RD91
BTA26-xxxBRG X X 50 mA Standard TOP3 Ins.
BTA26-xxxBWRG X X 50 mA Snubberless TOP3 Ins.
BTA26-xxxCWRG X X 35 mA Snubberless TOP3 Ins.
T2535-xxxG X X 35 mA Snubberless D
2
PA K
BT A 24 - 600 BW RG
Triac series
Insulation
Current
Voltage
Sensitivity and type
Packing mode
A = insulated
B = non insulated
24 = 25A in TO-220AB
25 = 25A in RD91
26 = 25A in TOP3
600 = 600V
800 = 800V
B = 50mA Standard BW = 50mA Snubberless
CW = 35mA
RG = Tube
Snubberless
T 25 35 - 600 G (-TR)
Triac series
Sensitivity
Voltage
Package
Packing mode
Current
25 = 25A
35 = 35mA
600 = 600V
800 = 800V
G = D PAK
Blanck = Tube
-TR = Tape & Reel
2
BTA24, BTB24, BTA25, BTA26
and T25 series
2014-6-16
www.kersemi.com
6
