© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com C1002_X7R_SMD • 4/30/2014 1
One world. One KEMET
Benets
• -55°C to +125°C operating temperature range
• Lead (Pb)-Free, RoHS, and REACH Compliant
• Temperature stable dielectric
• EIA 0402, 0603, 0805, 1206, 1210, 1808, 1812, 1825, 2220,
and 2225 case sizes
• DC voltage ratings of 6.3 V, 10 V, 16 V, 25 V, 50 V, 100 V,
200 V, and 250 V
• Capacitanceofferingsrangingfrom10pFto47μF
• Available capacitance tolerances of ±5%, ±10%, and ±20%
• Non-polar device, minimizing installation concerns
• 100%puremattetin-platedterminationnishallowingfor
excellent solderability
• SnPbterminationnishoptionavailableuponrequest
(5% minimum)
Applications
Typicalapplicationsincludedecoupling,bypass,lteringand
transient voltage suppression.
Overview
KEMET’s X7R dielectric features a 125°C maximum operating
temperatureandisconsidered“temperaturestable.”The
Electronics Components, Assemblies & Materials Association
(EIA)characterizesX7RdielectricasaClassIImaterial.
Componentsofthisclassicationarexed,ceramicdielectric
capacitors suited for bypass and decoupling applications or
forfrequencydiscriminatingcircuitswhereQandstabilityof
capacitancecharacteristicsarenotcritical.X7Rexhibitsa
predictablechangeincapacitancewithrespecttotimeand
voltageandboastsaminimalchangeincapacitancewith
referencetoambienttemperature.Capacitancechangeislimited
to ±15% from -55°C to +125°C.
SurfaceMountMultilayerCeramicChipCapacitors(SMDMLCCs)
X7R Dielectric, 6.3 – 250 VDC (Commercial Grade)
Ordering Information
C 1206 C 106 M 4 R A C TU
Ceramic
Case Size
(L" x W")
Specication/
Series
1
Capacitance
Code (pF)
Capacitance
Tolerance
Voltage Dielectric
Failure Rate/
Design
TerminationFinish
2
Packaging/Grade
(C-Spec)
3
0402
0603
0805
1206
1210
1808
1812
1825
2220
2225
C = Standard 2Signicant
Digits + Number
of Zeros
J = ±5%
K = ±10%
M = ±20%
9 = 6.3 V
8 = 10 V
4 = 16 V
3 = 25 V
6 = 35 V
5 = 50 V
1 = 100 V
2 = 200 V
A = 250 V
R = X7R A = N/A C = 100% Matte Sn Blank = Bulk
TU = 7" Reel
Unmarked
TM = 7" Reel
Marked
1
Flexible termination option is available. Please see FT-CAP product bulletin C1013_X7R_FT-CAP_SMD.
2
Additional termination nish options may be available. Contact KEMET for details.
3
Additional reeling or packaging options may be available. Contact KEMET for details.
Click image above for interactive 3D content
Open PDF in Adobe Reader for full functionality
