An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
CC2564MODN, CC2564MODA
SWRS160E –FEBRUARY 2014–REVISED JANUARY 2017
CC2564MODx Bluetooth
®
Host Controller Interface (HCI) Module
1 Device Overview
1
1.1 Features
1
• Module Solution Based on TI's CC2564B Dual-
Mode Bluetooth
®
, Available in Two Variants:
– CC2564MODA With Integrated Antenna
– CC2564MODN With External Antenna
• Fully Certified Module for FCC, IC, CE, and
Bluetooth 4.1
– FCC (Z64-2564N), IC (451I-2564N) Modular
Grant (see Section 6.2.1.3, Section 7.1.1, and
Section 7.1.2)
– CE Certified as Summarized in the Declaration
of Conformity (see Section 7.1.3)
– Bluetooth 4.1 Controller Subsystem Qualified
(CC2564MODN: QDID 55257; CC2564MODA:
QDID 64631). Compliant up to the HCI Layer
• Highly Optimized for Design Into Small Form
Factor Systems and Flexibility:
– CC2564MODA
– Integrated Chip Antenna
– Module Footprint: 35 Terminals, 0.8-mm
Pitch, 7 mm × 14 mm × 1.4 mm (Typical)
– CC2564MODN
– Single-Ended 50-Ω RF Interface
– Module Footprint: 33 Terminals, 0.8-mm
Pitch, 7 mm × 7 mm × 1.4 mm (Typical)
• BR and EDR Features Include:
– Up to Seven Active Devices
– Scatternet: Up to Three Piconets
Simultaneously, One as Master and Two as
Slaves
– Up to Two Synchronous Connection Oriented
(SCO) Links on the Same Piconet
– Support for All Voice Air-Coding—Continuously
Variable Slope Delta (CVSD), A-Law, µ-Law,
and Transparent (Uncoded)
– Assisted Mode for HFP 1.6 Wideband Speech
(WBS) Profile or A2DP Profile to Reduce Host
Processing and Power
– Support of Multiple Bluetooth Profiles With
Enhanced QoS
• Low Energy Features Include:
– Support of up to 10 Simultaneous Connections
– Multiple Sniff Instances Tightly Coupled to
Achieve Minimum Power Consumption
– Independent Buffering for Low Energy Allows
Large Numbers of Multiple Connections Without
Affecting BR or EDR Performance
– Built-In Coexistence and Prioritization Handling
for BR, EDR, and Low Energy
• Best-in-Class Bluetooth (RF) Performance (TX
Power, RX Sensitivity, Blocking)
– Class 1.5 TX Power up to +10 dBm
– –93 dbm Typical RX Sensitivity
– Internal Temperature Detection and
Compensation to Ensure Minimal Variation in
RF Performance Over Temperature, No
External Calibration Required
– Improved Adaptive Frequency Hopping (AFH)
Algorithm With Minimum Adaptation Time
– Provides Longer Range, Including Twice the
Range of Other Low-Energy-Only Solutions
• Advanced Power Management for Extended
Battery Life and Ease of Design
– On-Chip Power Management, Including Direct
Connection to Battery
– Low Power Consumption for Active, Standby,
and Scan Bluetooth Modes
– Shutdown and Sleep Modes to Minimize Power
Consumption
• Physical Interfaces:
– UART Interface With Support for Maximum
Bluetooth Data Rates
– UART Transport Layer (H4) With Maximum
Rate of 4 Mbps
– Three-Wire UART Transport Layer (H5) With
Maximum Rate of 4 Mbps
– Fully Programmable Digital Pulse-Code
Modulation (PCM)–I2S Codec Interface
• CC256x Bluetooth Hardware Evaluation Tool:
PC-Based Application to Evaluate RF Performance
of the Device and Configure Service Pack
