www.vishay.com For technical questions contact: CDC@vishay.com Document Number: 28511
26 Revision: 23-Feb-05
LV 100 V
Vishay BCcomponents
Ceramic Disc Capacitors
Class 1 and 2, 100 V (DC) General Purpose
Notes
1. Maximum thickness 4.0 mm.
2. SH = seated height.
3. Packaging codes refer to inward kinked leads. Other styles available on request.
4. 3
rd
digit to complete RoHS catalog number. 8
th
and 9
th
digit of the catalog number to be completed with the packaging code.
CLASS 2 Z5U
1000
± 20
5.0
5.0 4.0
D102M20Z5UH6.J5.
06 08 10
22.2 646 ..022
1500 D152M20Z5UH6.J5. 22.2 646 ..122
2200 D222M20Z5UH6.J5. 22.2 646 ..222
3300 D332M20Z5UH6.J5. 22.2 646 ..322
4700
6.5
D472M25Z5UH6.J5. 22.2 646 ..422
6800 D682M25Z5UH6.J5. 22.2 646 ..622
10000 7.5 D103M29Z5UH6.J5. 22.2 646 ..032
15000 8.5 D153M33Z5UH6.J5. 22.2 646 ..132
22000 10.0 D223M39Z5UH6.J5. 22.2 646 ..232
CLASS 2 Y5V
1000
+ 80/− 20 %
5.0
5.0 4.0
D102Z20Y5VH6.J5.
06 08 10
22.2 636 ..023
1500 D152Z20Y5VH6.J5. 22.2 636 ..123
2200 D222Z20Y5VH6.J5. 22.2 636 ..223
3300 D322Z20Y5VH6.J5. 22.2 636 ..323
4700
6.5
D472Z20Y5VH6.J5. 22.2 636 ..423
6800 D682Z25Y5VH6.J5. 22.2 636 ..623
10000 7.5 D103Z29Y5VH6.J5. 22.2 636 ..033
15000 8.5 D153Z33Y5VH6.J5. 22.2 636 ..133
22000 10.0 D223Z39Y5VH6.J5. 22.2 636 ..233
CLASS 2 Z5V
4700
+ 80/− 20 %
5.0
5.0 4.0
D472Z20Z5VH6.J5.
06 08 10
22.2 656 ..423
10000 6.5 D103Z25Z5VH6.J5. 22.2 656 ..033
22000 8.5 D223Z33Z5VH6.J5. 22.2 656 ..233
47000 11.0 D473Z43Z5VH6.J5. 22.2 656 ..433
ORDERING INFORMATION, CLASS 2, 100 V (DC), KINKED
C
(pF)
TOL.
(%)
D
max
(mm)
LEAD
SPACING
F
(mm)
SH
(2)
(mm)
CLEAR TEXT CODE
PACKAGING CODE
8
th
AND 9
th
DIGIT
(3)
CATALOG
NUMBER
(4)
3
rd
DIGIT:
5 = STANDARD
8 = RoHS
COMPLIANT
13
th
DIGIT:
T = REEL; U = AMMO;
3 = BULK
16
th
DIGIT:
R = RoHS COMPLIANT
REEL AMMO BULK
Note
1. The capacitors are supplied in bulk packaging (cardboard boxes), in tape on reel or in ammopack.
PACKAGING
D
max
(mm)
SIZE CODE
PACKAGING QUANTITIES
BULK REEL AMMO
5.0 (0.20") 20
1000 2500 2000
6.5 (0.25") 25
7.5 (0.29") 29
8.5 (0.33") 33
10.0 (0.39") 39
11.0 (0.43") 43
