General Information
www.vishay.com
Vishay BCcomponents
Revision: 31-Jul-15
5
Document Number: 28536
For technical questions, contact: cdc@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
CLASS 1 CERAMIC TYPE
TEMPERATURE COEFFICIENT OF THE CAPACITANCE FOR CLASS 1 CERAMIC CAPACITORS
C = capacitance change
= temperature coefficient in 10
-6
/°C
= temperature change in °C
VOLTAGE DEPENDENCE OF CAPACITANCE
None
FREQUENCY DEPENDENCE OF CAPACITANCE
Max. -2 % at 10 MHz
DISSIPATION FACTOR
• For values greater than 50 pF: see datasheet
• For lower values the dissipation factor is calculated according to the type of ceramic (rated temperature coefficient) under
consideration of the capacitance acc. to EN 130600.
• The dissipation factor as well as the measuring method to be agreed between manufacturer and user for values lower than
5 pF.
C
C
--------
% = 100 x x
NP0 (C0G)
NP0 (C0G)
85
-55 -40 -20
020406080100120
5
4
3
2
1
0
-1
-2
-3
-4
-5
C
ΔC
[%
]
υ u (°C)
N750 (U2J)
N750 (U2J)
10
0
C
ΔC
[%]
-50
-40
-30
-20
-10
20
30
40
50
85
υ u (°C)
-55 -40 -20
020406080100120
Temperature (°C)
1000
0
-1000
-2000
-60 -40 -20 0 20 40 60 80 100 120 140 160
350
SL0
Capacitance Change ΔC/C (ppm)
from +25 °C Reading
Temperature (°C)
-60
-40
-20
20
40
60
0
-55 -40 -20 0 10 25 45 65 85 105125 150
Capacitance Change ΔC/C (%)
S3N
