LC1D25E7 数据手册 - Schneider Electric（施耐德）
制造商:
Schneider Electric（施耐德）
分类:
工业继电器/通用
描述:
3 极接触器，交流控制，额定功率：18KW使用类别 AC3 415V 交流开关电压 3 极常开 切换功率 | 额定电流 | 高度(mm) | 宽度(mm) | 深度(mm) ---|---|---|---|--- 4 kW | 9 A | 77 | 45 | 86 5.5 kW | 12 A | 77 | 45 | 86 9 kW | 18 A | 77 | 45 | 86 11 kW | 25 A | 85 | 45 | 92 15 kW | 32 A | 85 | 45 | 92 18.5 kW | 38 A | 85 | 45 | 92 22 kW | 40 A | 127 | 75 | 119 25 kW | 50 A | 127 | 75 | 119 37 kW | 65 A | 127 | 75 | 119 45 kW | 80 A | 127 | 85 | 130 59 kW | 115 A | 158 | 120 | 136 80 kW | 150 A | 158 | 120 | 136 以L结尾的部件号 | 低消耗线圈 ---|--- LC1Dxx**3**xx | 通过弹簧接线端子或螺钉接线端子连接。 ### 认可UL 和 CSA### Schneider Electric TeSys D 系列
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
LC1D25E7数据手册
Page:
of 14 Go
若手册格式错乱，请下载阅览PDF原文件
5/194
Selection
5
Operational current and power conforming to IEC (θ y 60 °C)
Contactor size LC1/
LP1
K06
LC1/
LP1
K09
LC1
K12
LC1
K16
LC1
D09
LC1
D12
LC1
D18
LC1
D25
LC1
D32
LC1
D38
LC1
D40A
Maximum operational current
in AC-3
y 440 V A 6 9 12 16 9 12 18 25 32 38 40
Rated operational power P
(standard motor power ratings)
220/240 V kW 1.5 2.2 3 3 2.2 3 4 5.5 7.5 9 11
380/400 V kW 2.2 4 5.5 7.5 4 5.5 7.5 11 15 18.5 18.5
415 V kW 2.2 4 5.5 7.5 4 5.5 9 11 15 18.5 22
440 V kW 3 4 5.5 7.5 4 5.5 9 11 15 18.5 22
500 V kW 3 4 4 5.5 5.5 7.5 10 15 18.5 18.5 22
660/690 V kW 3 4 4 4 5.5 7.5 10 15 18.5 18.5 30
1000 V kW – – – – – – – – – – –
Maximum operating rate in operating cycles/hour (1)
On-load factor Operational
power
LC1
D09
LC1
D12
LC1
D18
LC1
D25
LC1
D32
LC1
D38
LC1
D40A
y 85 % P – – – – 1200 1200 1200 1200 1000 1000 1000
0.5 P – – – – 3000 3000 2500 2500 2500 2500 2500
y 25 % P – – – – 1800 1800 1800 1800 1200 1200 1200
Operational current and power conforming to UL, CSA (θ y 60 °C)
Contactor size LC1/
LP1
K06
LC1/
LP1
K09
LC1/
LP1
K12
LC1
D09
LC1
D12
LC1
D18
LC1
D25
LC1
D32
LC1
D38
LC1
D40A
Maximum operational current
in AC-3
y 440 V A 6 9 12 9 12 18 25 32 – 40
Rated operational power P
(standard motor power ratings
60 Hz)
200/208 V HP 1.5 2 3 2 3 5 7.5 10 – 10
230/240 V HP 1.5 3 3 2 3 5 7.5 10 – 10
460/480 V HP 3 5 7.5 5 7.5 10 15 20 – 30
575/600 V HP 3 5 10 7.5 10 15 20 25 – 30
(1) Depending on the operational power and the on-load factor (θ y 60 °C).
TeSys contactors 5
For utilisation category AC-3
1
2
3
4
5
6
7
8
9
10
