PCM2900CDB数据手册
Page:
of 33 Go
若手册格式错乱，请下载阅览PDF原文件
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
D+
D-
V
BUS
DGNDU
HID0
HID1
HID2
SEL0
SEL1
V
CCCI
AGNDC
V L
IN
V R
IN
V
COM
SSPND
DIN
V
CCXI
AGNDX
XTO
V
CCP2I
DGND
V
CCP1I
V L
OUT
XTI
DOUT
V
DDI
AGNDP
V R
OUT
PCM2902C
PCM2900C
PCM2902C
www.ti.com
SBFS039 –SEPTEMBER 2011
PCM2902C PIN ASSIGNMENTS
DB PACKAGE
SSOP-28
(TOP VIEW)
Table 2. PCM2902C TERMINAL FUNCTIONS
TERMINAL
NAME NO. I/O DESCRIPTION
AGNDC 11 – Analog ground for codec
AGNDP 18 – Analog ground for PLL
AGNDX 22 – Analog ground for oscillator
D– 2 I/O USB differential input/output minus
(1)
D+ 1 I/O USB differential input/output plus
(1)
DGND 26 – Digital ground
DGNDU 4 – Digital ground for USB transceiver
DIN 24 I S/PDIF input
(2)
DOUT 25 O S/PDIF output
HID0 5 I HID key state input (mute), active high
(3)
HID1 6 I HID key state input (volume up), active high
(3)
HID2 7 I HID key state input (volume down), active high
(3)
SEL0 8 I Must be set to high
(4)
SEL1 9 I Must be set to high
(4)
SSPND 28 O Suspend flag, active-low (low: suspend, high: operational)
V
BUS
3 – Connect to USB power (V
BUS
)
V
CCCI
10 – Internal analog power supply for codec
(5)
V
CCP1I
17 – Internal analog power supply for PLL
(5)
V
CCP2I
19 – Internal analog power supply for PLL
(5)
V
CCXI
23 – Internal analog power supply for oscillator
(5)
V
COM
14 – Common for ADC/DAC (V
CCCI
/2)
(5)
V
DDI
27 – Internal digital power supply
V
IN
L 12 I ADC analog input for L-channel
V
IN
R 13 I ADC analog input for R-channel
V
OUT
L 16 O DAC analog output for L-channel
V
OUT
R 15 O DAC analog output for R-channel
XTI 21 I Crystal oscillator input
(6)
XTO 20 O Crystal oscillator output
(1) LV-TTL level.
(2) 3.3-V CMOS-level input with internal pull-down, 5-V tolerant.
(3) 3.3-V CMOS-level input with internal pull-down. This pin informs the PC of serviceable control signals such as mute, volume up, or
volume down, which have no connection with the internal DAC or ADC directly. See the Interface #3 and End-Points sections.
(4) TTL Schmitt trigger, 5-V tolerant.
(5) Connect a decoupling capacitor to GND.
(6) 3.3-V, CMOS-level input.
Copyright © 2011, Texas Instruments Incorporated Submit Documentation Feedback 7
Product Folder Link(s): PCM2900C PCM2902C
