PIC12/16(L)F161X
DS40001745A-page 2 Advance Information 2014 Microchip Technology Inc.
Intelligent Analog Peripherals:
• 10-Bit Analog-to-Digital Converter (ADC):
- Up to 12 external channels
- Conversion available during Sleep
• Two Comparators (CMP):
- Low-Power/High-Speed mode
- Up to three external inverting inputs
- Fixed Voltage Reference at non-inverting
input(s)
- Comparator outputs externally accessible
• 8-Bit Digital-to-Analog Converter (DAC):
- 8-bit resolution, rail-to-rail
- Positive Reference Selection
• Voltage Reference:
- Fixed Voltage Reference (FVR): 1.024V,
2.048V and 4.096V output levels
• Zero-Cross Detect (ZCD):
- Detect when AC signal on pin crosses
ground
Clocking Structure:
• 16 MHz Internal Oscillator:
- ±1% at calibration
- Selectable frequency range from 32 MHz to
31 kHz
• 31 kHz Low-Power Internal Oscillator
• 4x Phase-Locked Loop (PLL):
- For up to 32 MHz internal operation
• External Oscillator Block with:
- Three external clock modes up to 32 MHz
TABLE 1: PIC12/16(L)F161X FAMILY TYPES
Device
Data Sheet Index
Program Memory Flash
(W)
Data SRAM
(bytes)
I/O Pins
8-bit/16-bit Timers
Comparators
10-bit ADC (ch)
Zero-Cross Detect
CCP/10-bit PWM
CWG
CLC
SMT/HLT
Angular Timer
Window Watchdog
Timer
CRC with Memory Scan
Math Accelerator
PPS
EUSART
I
2
C™/SPI
Debug
(1)
PIC12(L)F1612 (A) 2048 256 6 1/1 1 4 1 2/0 1 0 2/3 0 Y Y 0 0 0 0 I/H
PIC16(L)F1613 (A) 2048 256 12 1/1 2 8 1 2/0 1 0 2/3 0 Y Y 0 0 0 0 I/H
PIC16(L)F1614 (B) 4096 512 12 1/3 2 8 1 2/2 1 2 2/3 1 Y Y 1 Y 1 1 I/H
PIC16(L)F1615 (C) 8192 1024 12 1/3 2 8 1 2/2 1 4 2/3 1 Y Y 1 Y 1 1 I/H
PIC16(L)F1618 (B) 4096 512 18 1/3 2 12 1 2/2 1 2 2/3 1 Y Y 1 Y 1 1 I/H
PIC16(L)F1619 (C) 8192 1024 18 1/3 2 12 1 2/2 1 4 2/3 1 Y Y 1 Y 1 1 I/H
Note 1: Debugging Methods: (I) – Integrated on Chip; (H) – via ICD Header; E – using Emulation Product.
Data Sheet Index:
A. DS40001737 PIC12(L)F1612/16(L)F1613 Data Sheet, 8/14-Pin, 8-bit Flash Microcontrollers
B. Future Release PIC16(L)F1614/8 Data Sheet, 14/20-Pin, 8-bit Flash Microcontrollers
C. Future Release PIC16(L)F1615/9 Data Sheet, 14/20-Pin, 8-bit Flash Microcontrollers
Note: For other small form-factor package availability and marking information, please visit
http://www.microchip.com/packaging or contact your local sales office.
