2013 Microchip Technology Inc. Preliminary DS40001715B-page 13
PIC16(L)F1704/8
OUT
(2)
C1OUT — CMOS Comparator output.
C2OUT — CMOS Comparator output.
CCP1 — CMOS Capture/Compare/PWM1 output.
CCP2 — CMOS Capture/Compare/PWM2 output.
PWM3OUT — CMOS PWM3 output.
PWM4OUT — CMOS PWM4 output.
COGA — CMOS Complementary Output Generator Output A.
COGB — CMOS Complementary Output Generator Output B.
COGC — CMOS Complementary Output Generator Output C.
COGD — CMOS Complementary Output Generator Output D.
SDA
(3)
—ODI
2
C™ data input/output.
SDO — CMOS SPI data output.
SCK — CMOS SPI clock output.
SCL
(3)
I
2
CODI
2
C™ clock output.
TX/CK — CMOS USART asynchronous TX data/synchronous clock output.
DT — CMOS USART synchronous data output.
CLC1OUT — CMOS Configurable Logic Cell 1 source output.
CLC2OUT — CMOS Configurable Logic Cell 2 source output.
CLC3OUT — CMOS Configurable Logic Cell 3 source output.
TABLE 1-2: PIC16(L)F1704 PINOUT DESCRIPTION (CONTINUED)
Name Function
Input
Type
Output
Type
Description
Legend: AN = Analog input or output CMOS= CMOS compatible input or output OD = Open Drain
TTL = TTL compatible input ST = Schmitt Trigger input with CMOS levels I
2
C™ = Schmitt Trigger input with I
2
C
HV = High Voltage XTAL = Crystal levels
Note 1: Default peripheral input. Input can be moved to any other pin with the PPS input selection registers. See Register 12-1.
2: All pin outputs default to PORT latch data. Any pin can be selected as a digital peripheral output with the PPS output
selection registers. See Register 12-3.
3: These I
2
C functions are bidirectional. The output pin selections must be the same as the input pin selections.
