PIC16(L)F1703/7
DS40001722C-page 12 2013-2015 Microchip Technology Inc.
RC3/AN7/OPA2OUT/CCP2
(1)
/SS
(1)
RC3 TTL/ST CMOS General purpose I/O.
AN7 AN — ADC Channel 7 input.
OPA2OUT
—AN
Operational Amplifier 2 output.
CCP2 TTL/ST — Capture/Compare/PWM2.
SS
TTL/ST — Slave Select input.
RC4/OPA2IN- RC4 TTL/ST CMOS General purpose I/O.
OPA2IN- AN — Operational Amplifier 2 inverting input.
RC5/OPA2IN+/CCP1
(1)
RC5 TTL/ST CMOS General purpose I/O.
OPA2IN+ AN — Operational Amplifier 2 non-inverting input.
CCP1 TTL/ST — Capture/Compare/PWM1.
V
DD VDD Power — Positive supply.
V
SS VSS Power — Ground reference.
OUT
(2)
CCP1 — CMOS Capture/Compare/PWM1 output.
CCP2 — CMOS Capture/Compare/PWM2 output.
SDA
(3)
—ODI
2
C data input/output.
SDO — CMOS SPI data output.
SCK — CMOS SPI clock output.
SCL
(3)
—ODI
2
C clock output.
TABLE 1-2: PIC16(L)F1703 PINOUT DESCRIPTION (CONTINUED)
Name Function
Input
Type
Output
Type
Description
Legend: AN = Analog input or output CMOS= CMOS compatible input or output OD = Open Drain
TTL = TTL compatible input ST = Schmitt Trigger input with CMOS levels I
2
C = Schmitt Trigger input with I
2
C
HV = High Voltage
Note 1: Default peripheral input. Input can be moved to any other pin with the PPS input selection registers. See Register 12-1.
2: All pin outputs default to PORT latch data. Any pin can be selected as a digital peripheral output with the PPS output
selection registers. See Register 12-3.
3: These I
2
C functions are bidirectional. The output pin selections must be the same as the input pin selections.
