2003 Microchip Technology Inc. Advance Information DS40047B-page 1
PIC16F684
HIGH PERFORMANCE RISC CPU
• Only 35 instructions to learn
- All single cycle instructions except branches
• Operating speed:
- DC - 20 MHz oscillator/clock input
- DC - 200 ns instruction cycle
• Interrupt capability
• 8-level deep hardware stack
• Direct, Indirect, and Relative Addressing modes
SPECIAL MICROCONTROLLER
FEATURES
• Precision Internal Oscillator
- Factory calibrated to ±1%
- Software selectable frequency range of
8 MHz to 32 kHz
- Two-speed Start-up mode
- Crystal fail detect for critical applications
- Clock mode switching during operation for
low power operation
• Power saving SLEEP mode
• Wide operating voltage range (2.0V - 5.5V)
• Industrial and extended temperature range
• Power-on Reset (POR)
• Power-up Timer (PWRT) and Oscillator Start-up
Timer (OST)
• Brown-out Detect (BOD) with software control
option
• Enhanced low current Watchdog Timer (WDT)
with on-chip oscillator (software selectable
nominal 268 seconds with full prescaler) with
software enable
• Multiplexed Master Clear/Input pin
• Programmable code protection
• High Endurance FLASH/EEPROM cell
- 100,000 write FLASH endurance
- 1,000,000 write EEPROM endurance
- FLASH/data EEPROM retention: > 40 years
LOW POWER FEATURES
• Standby Current:
- 1 nA @ 2.0V, typical
• Operating Current:
-8.5µA @ 32 kHz, 2.0V, typical
-100µA @ 1 MHz, 2.0V, typical
PERIPHERAL FEATURES
• 11 I/O pins and 1 input-only pin
- High current source/sink for direct LED drive
- Interrupt-on-pin change
- Individually programmable weak pull-ups
- Low power wake-up
• Analog comparator module with:
- Two analog comparators
- Programmable on-chip voltage reference
(CV
REF) module (% of VDD)
- Comparator inputs and outputs externally
accessible
• A/D Converter
- 10-bit resolution and 8 channels
• Timer0: 8-bit timer/counter with 8-bit
programmable prescaler
• Enhanced Timer1
- 16-bit timer/counter with prescaler
- External Gate Input mode
- Option to use OSC1 and OSC2 in LP mode
as Timer1 oscillator, if INTOSC mode
selected
• Timer2: 8-bit timer/counter with 8-bit period
register, prescaler and postscaler
• Enhanced Capture, Compare, PWM module
- 16-bit Capture, max resolution 12.5 ns
- Compare, max resolution 200 ns
- 10-bit PWM with 1, 2 or 4 output channels,
programmable “dead time”, max frequency
20 kHz
• In-Circuit Serial Programming
TM
(ICSP
TM
) via two
pins
Device
Program
Memory
Data Memory
I/O
10-bit A/D
(ch)
Comparators
Timers
8/16-bit
FLASH
(words)
SRAM
(bytes)
EEPROM
(bytes)
PIC16F684 2048 128 256 12 8 2 2/1
14-Pin Low Power FLASH Microcontroller Product Brief
