DocID025451 Rev 3 35/121
STM32F071CB STM32F071RB STM32F071VB STM32F071V8 Pinouts and pin descriptions
38
M7 38 - - - PE7 I/O FT - TIM1_ETR -
L7 39 - - - PE8 I/O FT - TIM1_CH1N -
M8 40 - - - PE9 I/O FT - TIM1_CH1 -
L8 41 - - - PE10 I/O FT - TIM1_CH2N -
M9 42 - - - PE11 I/O FT - TIM1_CH2 -
L9 43 - - - PE12 I/O FT -
SPI1_NSS, I2S1_WS,
TIM1_CH3N
-
M10 44 - - - PE13 I/O FT -
SPI1_SCK, I2S1_CK,
TIM1_CH3
-
M11 45 - - - PE14 I/O FT -
SPI1_MISO, I2S1_MCK,
TIM1_CH4
-
M12 46 - - - PE15 I/O FT -
SPI1_MOSI, I2S1_SD,
TIM1_BKIN
-
L10 47 29 21 E3 PB10 I/O FT -
SPI2_SCK, I2C2_SCL,
USART3_TX, CEC,
TSC_SYNC, TIM2_CH3
-
L11 48 30 22 G2 PB11 I/O FT -
USART3_RX, TIM2_CH4,
EVENTOUT, TSC_G6_IO1,
I2C2_SDA
-
F12 49 31 23 D3 VSS S - - Ground
G12 50 32 24 F2 VDD S - - Digital power supply
L12 51 33 25 E2 PB12 I/O FT -
TIM1_BKIN, TIM15_BKIN,
SPI2_NSS, I2S2_WS,
USART3_CK,
TSC_G6_IO2,
EVENTOUT
-
K12 52 34 26 G1 PB13 I/O FTf -
SPI2_SCK, I2S2_CK,
I2C2_SCL, USART3_CTS,
TIM1_CH1N, TSC_G6_IO3
-
K11 53 35 27 F1 PB14 I/O FTf -
SPI2_MISO, I2S2_MCK,
I2C2_SDA, USART3_RTS,
TIM1_CH2N, TIM15_CH1,
TSC_G6_IO4
-
Table 12. STM32F071CB/RB/VB/V8 pin definitions (continued)
Pin numbers
Pin name
(function upon
reset)
Pin
type
I/O structure
Notes
Pin functions
UFBGA100
LQFP100
LQFP64
LQFP48/UFQFPN48
WLCSP49
Alternate functions
Additional
functions
