STM32F071VBT6数据手册
Page:
of 125 Go
若手册格式错乱，请下载阅览PDF原文件
This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to
change without notice.
January 2014 DocID025451 Rev 1 1/125
STM32F071xB
ARM-based 32-bit MCU, 128 KB Flash, 12 timers,
ADC, DAC & communication interfaces, 2.0 - 3.6 V
Datasheet - preliminary data
Features
Core: ARM
®
32-bit Cortex™-M0 CPU,
frequency up to 48 MHz
Memories
– 128 Kbytes of Flash memory
– 16 Kbytes of SRAM with HW parity
checking
CRC calculation unit
Reset and power management
– Voltage range: 2.0 V to 3.6 V
– Power-on/Power down reset (POR/PDR)
– Programmable voltage detector (PVD)
– Low power modes: Sleep, Stop, Standby
–V
BAT
supply for RTC and backup registers
Clock management
– 4 to 32 MHz crystal oscillator
– 32 kHz oscillator for RTC with calibration
– Internal 8 MHz RC with x6 PLL option
– Internal 40 kHz RC oscillator
– Internal 48 MHz oscillator with automatic
trimming based on ext. synchronization
Up to 87 fast I/Os
– All mappable on external interrupt vectors
– Up to 68 I/Os with 5V tolerant capability
and 19 with independent supply V
DDIO2
7-channel DMA controller
One 12-bit, 1.0 μs ADC (up to 16 channels)
– Conversion range: 0 to 3.6 V
– Separate analog supply from 2.4 up to 3.6
One 12-bit D/A converter (with 2 channels)
Two fast low-power analog comparators with
programmable input and output
Up to 24 capacitive sensing channels for
touchkey, linear and rotary touch sensors
Calendar RTC with alarm and periodic wakeup
from Stop/Standby
12 timers
– One 16-bit advanced-control timer for
6 channel PWM output
– One 32-bit and seven 16-bit timers, with up
to 4 IC/OC, OCN, usable for IR control
decoding or DAC control
– Independent and system watchdog timers
– SysTick timer
Communication interfaces
– Two I
2
C interfaces supporting Fast Mode
Plus (1 Mbit/s) with 20 mA current sink; one
supporting SMBus/PMBus and wakeup
– Four USARTs supporting master
synchronous SPI and modem control; two
with ISO7816 interface, LIN, IrDA, auto
baud rate detection and wakeup feature
– Two SPIs (18 Mbit/s) with 4 to 16
programmable bit frames, and with I
2
S
interface multiplexed
HDMI CEC, wakeup on header reception
Serial wire debug (SWD)
96-bit unique ID
All packages ECOPACK
®
2
Table 1. Device summary
Reference Part number
STM32F071xB
STM32F071CB, STM32F071RB,
STM32F071VB
LQFP100 14x14 mm
LQFP64 10x10 mm
LQFP48 7x7 mm
UFQFPN48
7x7 mm
WLCSP49
0.4 mm pitch
UFBGA100
7x7 mm
www.st.com
