STM32F100VCT6B 数据手册 - ST Microelectronics（意法半导体）
制造商:
ST Microelectronics（意法半导体）
分类:
微控制器
封装:
LQFP-100
描述:
STM32F100 超值系列微处理器，STMicroelectronicsSTM32F100 超值型基于 ARM Cortex™ M3 MCU，包含带电动机控制和 CEC 功能的 24 MHz CPU。 STM32 系列 ARM Cortex-M3 32 位闪存微控制器产品系列在低功率、低电压情况下运行，结合了带有实时功能的高性能。 它们为引脚到引脚接线并兼容软件。 STMicroelectronics 高级 ARM 32 位处理器低密度和中密度超值型带高达 512 KB 的闪存、计时器、ADC、DAC 和通信接口，还提供不同的封装。 ST 的 STM32F100 微控制器系列适用于多种区域，例如应用控制和用户接口；医疗和手持设备；PC 和游戏外设；GPS 平台和工业应用。 32 位 RISC；高达 512 KB 闪存；高达 32 KB SRAM 温度范围：- 40 至 +85 °C 低电压：2 V 至 3.6 V ### STM32F1 系列 32 位 ARM® Cortex®-M3 微控制器，STMicroelectronics32 位闪存微控制器的 STM32 系列基于 ARM Cortex™ M3 核心的突破 - 为嵌入式应用特别开发的核心。 STM32 系列得益于 Cortex-M3 体系结构增强功能，包括为传达改进性能而设置的 Thumb-2 指令，带更好的编码密度，对中断更快的反应，所有的均和领先的工业功耗相接合。出色的实时表现 卓越功效 卓越的和新型的外围设备 最大程度的集成 跨族引脚，外围设备和软件兼容性展开
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
引脚图在P23P24P25P26P27P28P29P30P31P32P33Hot
典型应用电路图在P52P54P86
封装尺寸在P91
型号编码规则在P101P102P103
封装信息在P91P92P93P94P95P96P97P98P99P100P101P102
技术参数、封装参数在P37P69
电气规格在P35P36P37P38P39P40P41P42P43P44P45P46
导航目录
STM32F100VCT6B数据手册
Page:
of 106 Go
若手册格式错乱，请下载阅览PDF原文件
This is information on a product in full production.
March 2016 DocID15081 Rev 10 1/106
STM32F100xC STM32F100xD
STM32F100xE
High-density value line, advanced ARM
®
-based 32-bit MCU with
256 to 512 KB Flash, 16 timers, ADC, DAC & 11 comm interfaces
Datasheet − production data
Features
• Core: ARM
®
32-bit Cortex
®
-M3
CPU
– 24 MHz maximum frequency, 1.25 DMIPS
/MHz (Dhrystone 2.1) performance
– Single-cycle multiplication and hardware
division
• Memories
– 256 to 512 Kbytes of Flash memory
– 24 to 32 Kbytes of SRAM
– Flexible static memory controller with 4
Chip Selects. Supports SRAM, PSRAM
and NOR memories
– LCD parallel interface, 8080/6800 modes
• Clock, reset and supply management
– 2.0 to 3.6 V application supply and I/Os
– POR, PDR and programmable voltage
detector (PVD)
– 4-to-24 MHz crystal oscillator
– Internal 8 MHz factory-trimmed RC
– Internal 40 kHz RC
– PLL for CPU clock
– 32 kHz oscillator for RTC with calibration
• Low power
– Sleep, Stop and Standby modes
–V
BAT
supply for RTC and backup registers
• Serial wire debug (SWD) and JTAG I/F
• DMA
– 12-channel DMA controller
– Peripherals supported: timers, ADC, SPIs,
I
2
Cs, USARTs and DACs
• 1 × 12-bit, 1.2 µs A/D converter (up to 16 ch.)
– Conversion range: 0 to 3.6 V
– Temperature sensor
• 2 × 12-bit D/A converters
• Up to 112 fast I/O ports
– 51/80/112 I/Os, all mappable on 16
external interrupt vectors and almost all
5 V-tolerant
• Up to 16 timers
– Up to seven 16-bit timers, each with up to 4
IC/OC/PWM or pulse counter
– One 16-bit, 6-channel advanced-control
timer: up to 6 channels for PWM output,
dead time generation and emergency stop
– One 16-bit timer, with 2 IC/OC, 1
OCN/PWM, dead-time generation and
emergency stop
– Two 16-bit timers, each with
IC/OC/OCN/PWM, dead-time generation
and emergency stop
– Two watchdog timers
– SysTick timer: 24-bit downcounter
– Two 16-bit basic timers to drive the DAC
• Up to 11 communications interfaces
– Up to two I
2
C interfaces (SMBus/PMBus)
– Up to 3 USARTs (ISO 7816 interface, LIN,
IrDA capability, modem control)
– Up to 2 UARTs
– Up to 3 SPIs (12 Mbit/s)
– Consumer electronics control (CEC) I/F
• CRC calculation unit, 96-bit unique ID
Table 1. Device summary
Reference Part number
STM32F100xC
STM32F100RC, STM32F100VC,
STM32F100ZC
STM32F100xD
STM32F100RD, STM32F100VD,
STM32F100ZD
STM32F100xE
STM32F100RE, STM32F100VE,
STM32F100ZE
LQFP100
14 × 14 mm
LQFP144
20 × 20 mm
LQFP64
10 × 10 mm
www.st.com
