This is information on a product in full production.
June 2015 DocID025147 Rev 5 1/137
STM32F302x6 STM32F302x8
ARM
®
Cortex
®
-M4 32-bit MCU+FPU, up to 64 KB Flash,
16 KB SRAM, ADC, DAC, USB, CAN, COMP, Op-Amp, 2.0 - 3.6 V
Datasheet - production data
Features
Core: ARM
®
32-bit Cortex
®
-M4 CPU with FPU
(72 MHz max.), single-cycle multiplication and
HW division, DSP instruction
Memories
– 32 to 64 Kbyte of Flash memory
– 16 Kbyte of SRAM on data bus
CRC calculation unit
Reset and power management
–V
DD
, V
DDA
voltage range: 2.0 to 3.6 V
– Power-on/Power down reset (POR/PDR)
– Programmable voltage detector (PVD)
– Low-power: Sleep, Stop, and Standby
–V
BAT
supply for RTC and backup registers
Clock management
– 4 to 32 MHz crystal oscillator
– 32 kHz oscillator for RTC with calibration
– Internal 8 MHz RC with x 16 PLL option
– Internal 40 kHz oscillator
Up to 51 fast I/O ports, all mappable on
external interrupt vectors, several 5 V-tolerant
Interconnect matrix
7-channel DMA controller supporting timers,
ADCs, SPIs, I
2
Cs, USARTs and DAC
1 × ADC 0.20 μs (up to 15 channels) with
selectable resolution of 12/10/8/6 bits, 0 to
3.6 V conversion range, single
ended/differential mode, separate analog
supply from 2.0 to 3.6 V
Temperature sensor
1 x 12-bit DAC channel
with analog supply from
2.4 to 3.6 V
Three fast rail-to-rail analog comparators with
analog supply from 2.0 to 3.6 V
1 x operational amplifier that can be used in
PGA mode, all terminal accessible with analog
supply from 2.4 to 3.6 V
Up to 18 capacitive sensing channels
supporting touchkey, linear and rotary sensors
Up to 9 timers
– One 32-bit timer with up to 4 IC/OC/PWM
or pulse counter and quadrature
(incremental) encoder input
– One 16-bit 6-channel advanced-control
timer, with up to 6 PWM channels,
deadtime generation and emergency stop
– Three 16-bit timers with IC/OC/OCN or
PWM, deadtime gen. and emergency stop
– One 16-bit basic timer to drive the DAC
– 2 watchdog timers (independent, window)
– SysTick timer: 24-bit downcounter
Calendar RTC with alarm, periodic wakeup
from Stop/Standby
Communication interfaces
– Three I2Cs with 20 mA current sink to
support Fast mode plus
– Up to 3 USARTs, 1 with ISO 7816 I/F,
autobaudrate detect and Dual clock
domain
– Up to two SPIs with multiplexed full duplex
I2S
– USB 2.0 full-speed interface
– 1 x CAN interface (2.0B Active)
– Infrared transmitter
Serial wire debug (SWD), JTAG
96-bit unique ID
Reference Part number
STM32F302x6 STM32F302R6, STM32F302C6, STM32F302K6
STM32F302x8 STM32F302R8, STM32F302C8, STM32F302K8
LQFP48 (7x7 mm)
LQFP64 (10x10 mm)
UFQFPN32
(5x5 mm)
WLCSP49
(3.417x3.151 mm)
www.st.com
