Ordering information STM8S105x4/6
108/121 DocID14771 Rev 15
13 Ordering information
Figure 61. STM8S105x4/6 access line ordering information scheme
(1)
1. A dedicated ordering information scheme will be released if, in the future, memory programming service
(FastROM) is required The letter “P” will be added after STM8S. Three unique letters identifying the
customer application code will also be visible in the codification. Example: STM8SP103K3MACTR.
For a list of available options (for example memory size, package) and orderable part
numbers or for further information on any aspect of this device, please go to www.st.com or
contact the nearest ST Sales Office.
STM8 S 105 K 4 T 6 TR
Product class
STM8 microcontroller
Program memory size
4 = 16 Kbyte
6 = 32 Kbyte
Package type
B = SDIP
T = LQFP
U = UFQFPN
Example:
Sub-family type
10x = Access line
105 sub-family
Family type
S = Standard
Temperature range
3 = -40 to 125 °C
6 = -40 to 85 °C
Packing
No character = Tray or tube
TR = Tape and reel
Pin count
K = 32 pins
S = 44 pins
C = 48 pins
Package pitch/thickness
Blank = 0.5 mm
C = 0.8 mm
A = 0.55 mm thickness for UFQFPN32
