TLC5940
SLVS515D –DECEMBER 2004–REVISED NOVEMBER 2015
www.ti.com
Pin Functions
PIN
TYPE DESCRIPTION
NAME DIP NO. PWP NO. RHB NO.
Blank all outputs. When BLANK = H, all OUTn outputs are forced OFF.
BLANK 23 2 31 I GS counter is also reset. When BLANK = L, OUTn are controlled by
grayscale PWM control.
Switch DC data input. When DCPRG = L, DC is connected to
EEPROM. When DCPRG = H, DC is connected to the DC register.
DCPRG 19 26 25 I
DCPRG also controls EEPROM writing, when VPRG = V
(PRG)
.
EEPROM data = 3 Fh (default)
GND 22 1 30 G Ground
GSCLK 18 25 24 I Reference clock for grayscale PWM control
IREF 20 27 26 I Reference current terminal
— — 12
— — 13
NC — No connection
— — 28
— — 29
OUT0 28 7 4 O Constant current output
OUT1 1 8 5 O Constant current output
OUT2 2 9 6 O Constant current output
OUT3 3 10 7 O Constant current output
OUT4 4 11 8 O Constant current output
OUT5 5 12 9 O Constant current output
OUT6 6 13 10 O Constant current output
OUT7 7 14 11 O Constant current output
OUT8 8 15 14 O Constant current output
OUT9 9 16 15 O Constant current output
OUT10 10 17 16 O Constant current output
OUT11 11 18 17 O Constant current output
OUT12 12 19 18 O Constant current output
OUT13 13 20 19 O Constant current output
OUT14 14 21 20 O Constant current output
OUT15 15 22 21 O Constant current output
SCLK 25 4 1 I Serial data shift clock
SIN 26 5 2 I Serial data input
SOUT 17 24 23 O Serial data output
VCC 21 28 27 I Power supply voltage
Multifunction input pin. When VPRG = GND, the device is in GS mode.
When VPRG = V
CC
, the device is in DC mode. When VPRG = V
(VPRG)
,
VPRG 27 6 3 I
DC register data can programmed into DC EEPROM with
DCPRG=HIGH. EEPROM data = 3 Fh (default)
Error output. XERR is an open-drain terminal. XERR goes L when LOD
XERR 16 23 22 O
or TEF is detected.
Level triggered latch signal. When XLAT = high, the TLC5940 writes
data from the input shift register to either GS register (VPRG = low) or
XLAT 24 3 32 I
DC register (VPRG = high). When XLAT = low, the data in GS or DC
register is held constant.
4 Submit Documentation Feedback Copyright © 2004–2015, Texas Instruments Incorporated
Product Folder Links: TLC5940
