24AA128/24LC128/24FC128
DS21191S-page 2 2010 Microchip Technology Inc.
1.0 ELECTRICAL CHARACTERISTICS
Absolute Maximum Ratings
(†)
VCC.............................................................................................................................................................................6.5V
All inputs and outputs w.r.t. VSS ......................................................................................................... -0.6V to VCC +1.0V
Storage temperature ...............................................................................................................................-65°C to +150°C
Ambient temperature with power applied................................................................................................-40°C to +125°C
ESD protection on all pins 4kV
TABLE 1-1: DC CHARACTERISTICS
† NOTICE: Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage to the
device. This is a stress rating only and functional operation of the device at those or any other conditions above those
indicated in the operational listings of this specification is not implied. Exposure to maximum rating conditions for
extended periods may affect device reliability.
DC CHARACTERISTICS
Electrical Characteristics:
Industrial (I): VCC = +1.7V to 5.5V TA = -40°C to +85°C
Automotive (E): V
CC = +2.5V to 5.5V TA = -40°C to 125°C
Param.
No.
Sym. Characteristic Min. Max. Units Conditions
— A0, A1, A2, SCL, SDA and
WP pins:
————
D1 V
IH High-level input voltage 0.7 VCC —V—
D2 V
IL Low-level input voltage — 0.3 VCC
0.2 VCC
V
V
VCC 2.5V
V
CC < 2.5V
D3 VHYS Hysteresis of Schmitt Trigger
inputs (SDA, SCL pins)
0.05 VCC —VVCC 2.5V (Note 1)
D4 V
OL Low-level output voltage — 0.40 V IOL = 3.0 mA @ VCC = 4.5V
I
OL = 2.1 mA @ VCC = 2.5V
D5 I
LI Input leakage current — ±1 AVIN = VSS or VCC, WP = VSS
VIN = VSS or VCC, WP = VCC
D6 ILO Output leakage current — ±1 AVOUT = VSS or VCC
D7 CIN,
C
OUT
Pin capacitance
(all inputs/outputs)
—10pFVCC = 5.0V (Note 1)
T
A = 25°C, FCLK = 1 MHz
D8 ICC Read Operating current — 400 AVCC = 5.5V, SCL = 400 kHz
I
CC Write — 3 mA VCC = 5.5V
D9 ICCS Standby current — 1 ATA = -40°C to +85°C
SCL = SDA = V
CC = 5.5V
A0, A1, A2, WP = V
SS
—5ATA = -40°C to 125°C
SCL = SDA = V
CC = 5.5V
A0, A1, A2, WP = V
SS
Note 1: This parameter is periodically sampled and not 100% tested.
