Transceiver Architecture in Cyclone V Devices
1
2016.01.28
CV-53001
Subscribe
Send Feedback
Describes the Cyclone
®
V transceiver architecture, clocking, channels, channel bonding, and transmitter
and receiver channel datapaths.
Altera
®
28-nm Cyclone V devices provide transceivers with the lowest power requirement at 3.125 and
6.144 Gigabits per second (Gbps). These transceivers comply with a wide range of protocols and data rate
standards; however, 6.144 Gbps support is limited to the common public radio interface (CPRI) protocol
only.
Cyclone V devices have up to 12 transceiver channels with serial data rates between 614 megabits per
second (Mbps) and 6.144 Gbps and have backplane-capable transceiver support for PCI Express
®
(PCIe
®
) Base Specification 2.0 Gen1 and Gen2 up to x4 bonded channels.
Cyclone V transceiver channels are full-duplex and clock data recovery (CDR)–based with physical
coding sublayer (PCS) and physical medium attachment (PMA) layers.
©
