1. General description
The 74HC4052; 74HCT4052 is a high-speed Si-gate CMOS device and is pin compatible
with the HEF4052B. The device is specified in compliance with JEDEC standard no. 7A.
The 74HC4052; 74HCT4052 is a dual 4-channel analog multiplexer/demultiplexer with
common select logic. Each multiplexer has four independent inputs/outputs (pins nY0 to
nY3) and a common input/output (pin nZ). The common channel select logics include two
digital select inputs (pins S0 and S1) and an active LOW enable input (pin E
). When
pin E
= LOW, one of the four switches is selected (low-impedance ON-state) with pins S0
and S1. When pin E
= HIGH, all switches are in the high-impedance OFF-state,
independent of pins S0 and S1.
V
CC
and GND are the supply voltage pins for the digital control inputs (pins S0, S1 and E).
The V
CC
to GND ranges are 2.0 V to 10.0 V for the 74HC4052 and 4.5 V to 5.5 V for the
74HCT4052. The analog inputs/outputs (pins nY0 to nY3 and nZ) can swing between V
CC
as a positive limit and V
EE
as a negative limit. V
CC
V
EE
may not exceed 10.0 V.
For operation as a digital multiplexer/demultiplexer, V
EE
is connected to GND (typically
ground).
2. Features and benefits
Wide analog input voltage range from 5 V to +5 V
Low ON resistance:
80 (typical) at V
CC
V
EE
=4.5V
70 (typical) at V
CC
V
EE
=6.0V
60 (typical) at V
CC
V
EE
=9.0V
Logic level translation: to enable 5 V logic to communicate with 5 V analog signals
Typical ‘break before make’ built-in
Complies with JEDEC standard no. 7A
ESD protection:
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-A exceeds 200 V
Specified from 40 Cto +85C and 40 Cto +125C
3. Applications
Analog multiplexing and demultiplexing
Digital multiplexing and demultiplexing
Signal gating
74HC4052; 74HCT4052
Dual 4-channel analog multiplexer/demultiplexer
Rev. 9 — 13 December 2011 Product data sheet
