(3/7)

20151227 / cmf_automotive_signal_acm2012_en.fm

Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.

Please note that the contents may change without any prior notice due to reasons such as upgrading.

EMC Components

Common Mode Filters

For automobile signal line

FEATURES

Highly reliable with a temperature range of –40 to +105°C.

Impedance variation: Four impedance values are available for compatibility with various usages.

Common mode EMI measure: Possible to suppress waveform common mode EMI without straining the waveform.

APPLICATION

Radiated noise suppression for car multimedia interfaces (MOST, USB2.0, IDB-1394, etc.).

PART NUMBER CONSTRUCTION

OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT



The Storage temperature range is for after the circuit board is mounted.

Overview of ACM2012 Type

ACM 2012 - 900 - 2P - T 001

Series name

L×W Dimensions Impedance

Number of lines Packaging style Internal code

(mm) (:) at 100MHz

2012 2.0×1.2 900 90 2P 2 lines T ø180mm reel 001

121 120

201 200

361 360

Type

Temperature range Reel diameter Package quantity Individual weight

Operating

temperature



（°C）

Storage

temperature



（°C）（mm）

(pieces/reel)

（mg）

ACM2012 –40 to +105 –40 to +105 ø180 2,000 10

Product compatible with RoHS directive

Compatible with lead-free solders

AEC-Q200

RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://product.tdk.com/en/environment/rohs/

Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
