(3/11)
001-01 / 20130723 / e9712_acm.fm
• All specifications are subject to change without notice.
EMC Components
Common Mode Filters
For high-speed differential signal line, general signal line
FEATURES
Downsized wound type chip common mode filter that maintains required common mode filter characteristics.
Impedance for common mode noise can clear 1000: [100MHz], and has excellent EMC suppression.
Differential mode impedance is suppressed, so there is virtually no affect on high speed signals.
There is a two-line type and a three-line type, so they can be used for various circuits and noise.
APPLICATION
Common mode noise countermeasure for high-speed differential signals where influence to the signal is a concern.
USB line for PCs and peripheral devices.
IEEE1394 lines and ETHERNET lines for PCs, STBs, etc.
LCD panel LVDS and Panel Link lines.
PART NUMBER CONSTRUCTION
OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT
The Storage temperature range is for after the circuit board is mounted.
Overview of the ACM Series
ACM 2012 - 900 - 2P - T - 002
Series name
L×W×H Dimensions Impedance
Number of lines Packaging style Internal code
(mm) (:) at 100MHz
2012 2.0×1.2×1.3 900 90 2P 2 lines T ø180mm reel
2520 2.5×2.0×1.2 201 200 3P 3 lines TL ø330mm reel
102 1000
Type
Temperature range
Reel diameter Package quantity Individual weight
Operating
temperature
Storage
temperature
（°C） （°C） （mm） （pieces/reel） （mg）
ACM2012 –40 to +85 –40 to +85
ø180 2,000
10
ø330 10,000
ACM2520 –40 to +85 –40 to +85
ø180 2,000
25
ø330 10,000
Product compatible with RoHS directive
Compatible with lead-free solders
RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://www.tdk.co.jp/rohs/
