Circuit Note
CN-0338
Circuits from the Lab® reference designs are engineered and
tested for quick and easy system integration to help solve today’s
analog, mixed-signal, and RF design challenges. For more
information and/or support, visit www.analog.com/CN0338.
Devices Connected/Referenced
AD8629
Zero-Drift, Single-Supply, Rail-to-Rail
Input/Output Operational Amplifier
ADA4528-1
Precision, Ultralow Noise, RRIO,
Zero-Drift Op Amp
ADP7105
20 V, 500 mA, Low Noise LDO Regulator
with Soft Start
ADuCM360
Low Power, Precision Analog
Microcontroller with Dual Sigma-Delta
ADCs, ARM Cortex-M3
NDIR Thermopile-Based Gas Sensing Circuit
Rev. 0
Circuits from the Lab® reference designs from Analog Devices have been designed and built by Analog
Devices engineers. Standard engineering practices have been employed in the design and
construction of each circuit, and their function and performance have been tested and verified in a lab
environment at room temperature. However, you are solely responsible for testing the circuit and
determining its suitability and applicability for your use and application. Accordingly, in no event shall
Analog Devices be liable for direct, indirect, special, incidental, consequential or punitive damages due
to any cause whatsoever connected to the use of any Circuits from the Lab circuits. (Continued on last page)
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781.329.4700 www.analog.com
Fax: 781.461.3113 ©2016 Analog Devices, Inc. All rights reserved.
EVALUATION AND DESIGN SUPPORT
Circuit Evaluation Boards
CN-0338 Circuit Evaluation Board
(EVAL-CN0338-ARDZ Shield)
Arduino-Compatible Platform Board
(EVAL-ADICUP360)
Design and Integration Files
Schematics, Layout Files, Bill of Materials, Source Code
CIRCUIT FUNCTION AND BENEFITS
The circuit shown in Figure 1 is a complete thermopile-based gas
sensor using the nondispersive infrared (NDIR) principle. This
circuit is optimized for CO
2
sensing, but can also accurately
measure the concentration of a large number of gases by using
thermopiles with different optical filters.
The printed circuit board (PCB) is designed in an Arduino
shield form factor and interfaces to the EVAL-ADICUP360
Arduino-compatible platform board. The signal conditioning is
implemented with the AD8629 and the ADA4528-1 low noise
amplifiers and the ADuCM360 precision analog microcontroller,
which contains programmable gain amplifiers, dual 24-bit Σ-Δ
analog-to-digital converters (ADCs), and an ARM Cortex-M3
processor.
