AC Electrical Characteristics (Continued)
The following specifications apply for V
CC
=5 V
DC
and T
MIN
≤T
A
≤T
MAX
unless otherwise specified.
Symbol Parameter Conditions Min Typ Max Units
C
OUT
TRI-STATE Output 5 7.5 pF
Capacitance (Data Buffers)
CONTROL INPUTS [Note: CLK IN (Pin 4) is the input of a Schmitt trigger circuit and is therefore specified separately]
V
IN
(1) Logical “1” Input Voltage V
CC
=5.25 V
DC
2.0 15 V
DC
(Except Pin 4 CLK IN)
V
IN
(0) Logical “0” Input Voltage V
CC
=4.75 V
DC
0.8 V
DC
(Except Pin 4 CLK IN)
I
IN
(1) Logical “1” Input Current V
IN
=5 V
DC
0.005 1 µA
DC
(All Inputs)
I
IN
(0) Logical “0” Input Current V
IN
=0 V
DC
−1 −0.005 µA
DC
(All Inputs)
CLOCK IN AND CLOCK R
V
T
+ CLK IN (Pin 4) Positive Going 2.7 3.1 3.5 V
DC
Threshold Voltage
V
T
− CLK IN (Pin 4) Negative 1.5 1.8 2.1 V
DC
Going Threshold Voltage
V
H
CLK IN (Pin 4) Hysteresis 0.6 1.3 2.0 V
DC
(V
T
+)−(V
T
−)
V
OUT
(0) Logical “0” CLK R Output I
O
=360 µA 0.4 V
DC
Voltage V
CC
=4.75 V
DC
V
OUT
(1) Logical “1” CLK R Output I
O
=−360 µA 2.4 V
DC
Voltage V
CC
=4.75 V
DC
DATA OUTPUTS AND INTR
V
OUT
(0) Logical “0” Output Voltage
Data Outputs I
OUT
=1.6 mA, V
CC
=4.75 V
DC
0.4 V
DC
INTR Output I
OUT
=1.0 mA, V
CC
=4.75 V
DC
0.4 V
DC
V
OUT
(1) Logical “1” Output Voltage I
O
=−360 µA, V
CC
=4.75 V
DC
2.4 V
DC
V
OUT
(1) Logical “1” Output Voltage I
O
=−10 µA, V
CC
=4.75 V
DC
4.5 V
DC
I
OUT
TRI-STATE Disabled Output V
OUT
=0 V
DC
−3 µA
DC
Leakage (All Data Buffers) V
OUT
=5 V
DC
3µA
DC
I
SOURCE
V
OUT
Short to Gnd, T
A
=25˚C 4.5 6 mA
DC
I
SINK
V
OUT
Short to V
CC
,T
A
=25˚C 9.0 16 mA
DC
POWER SUPPLY
I
CC
Supply Current (Includes f
CLK
=640 kHz,
Ladder Current) V
REF
/2=NC, T
A
=25˚C
and CS =5V
ADC0801/02/03/04LCJ/05 1.1 1.8 mA
ADC0804LCN/LCWM 1.9 2.5 mA
Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. DC andAC electrical specifications do not apply when operating
the device beyond its specified operating conditions.
Note 2: All voltages are measured with respect to Gnd, unless otherwise specified. The separate A Gnd point should always be wired to the D Gnd.
Note 3: A zener diode exists, internally, from V
CC
to Gnd and has a typical breakdown voltage of 7 V
DC
.
Note 4: For V
IN
(−)≥ V
IN
(+) the digitaloutput codewill be 0000 0000. Two on-chip diodes are tied toeach analoginput (see block diagram) which willforward conduct
for analog input voltages one diode drop below ground or one diode drop greater than the V
CC
supply. Be careful, during testing at low V
CC
levels (4.5V), as high
level analog inputs (5V) can cause this input diode to conduct–especially at elevated temperatures, and cause errors for analog inputs near full-scale. The spec
allows 50 mV forward bias of either diode. This means that as long as the analog V
IN
does not exceed the supply voltage by more than 50 mV, the output code will
be correct. To achieve an absolute 0 V
DC
to5V
DC
input voltage range will therefore require a minimum supply voltage of 4.950 V
DC
over temperature variations,
initial tolerance and loading.
Note 5: Accuracy is guaranteed at f
CLK
= 640 kHz. At higher clock frequencies accuracy can degrade. For lower clock frequencies, the duty cycle limits can be
extended so long as the minimum clock high time interval or minimum clock low time interval is no less than 275 ns.
Note 6: With an asynchronous start pulse, up to 8 clock periods may be required before the internal clock phases are proper to start the conversion process. The
start request is internally latched, see
Figure 4
and section 2.0.
ADC0801/ADC0802/ADC0803/ADC0804/ADC0805
www.national.com 4
