1. General description

The ADC0806030/040/050 are a family of 8-bit high-speed, low-power Analog-to-Digital

Converters (ADC) for professional video and other applications. It converts the analog

input signal into 8-bit binary coded digital signals at a maximum sampling rate of 50 MHz.

All digital inputs and outputs are Transistor-Transistor Logic (TTL) and CMOS compatible,

although a low-level sine wave clock input signal can also be used.

The device requires an external source to drive its reference ladder. If the application

requires that the reference is driven via internal sources, NXP recommends you use one

of the ADC1003S030/040/050 family.

at 4.43 MHz full-scale input at f

clk

= 40 MHz)

n No missing codes guaranteed

n In-Range (IR) CMOS output

n TTL and CMOS levels compatible digital inputs

n 3 V to 5 V CMOS digital outputs

n Low-level AC clock input signal allowed

n External reference voltage regulator

n Power dissipation only 175 mW (typical)

n Low analog input capacitance, no buffer amplifier required

n Medical imaging

n Barcode scanner

n Global Positioning System (GPS) receiver

ADC0804S030/040/050

Single 8 bits ADC, up to 30 MHz, 40 MHz or 50 MHz

Rev. 02 — 14 August 2008 Product data sheet
