ADC08200
www.ti.com
SNAS136M –APRIL 2001–REVISED MARCH 2013
ADC08200 8-Bit, 20 Msps to 200 Msps, Low Power A/D Converter with Internal Sample-
and-Hold
Check for Samples: ADC08200
1
FEATURES
DESCRIPTION
The ADC08200 is a low-power, 8-bit, monolithic
2
• Single-Ended Input
analog-to-digital converter with an on-chip track-and-
• Internal Sample-and-Hold Function
hold circuit. Optimized for low cost, low power, small
• Low Voltage (Single +3V) Operation
size and ease of use, this product operates at
conversion rates up to 230 Msps while consuming
• Small Package
just 1.05 mW per MHz of clock frequency, or 210 mW
• Power-Down Feature
at 200 Msps. Raising the PD pin puts the ADC08200
into a Power Down mode where it consumes about 1
KEY SPECIFICATIONS
mW.
• Resolution 8 Bits
The unique architecture achieves 7.3 Effective Bits
• Maximum sampling frequency 200 Msps (min)
with 50 MHz input frequency. The ADC08200 is
resistant to latch-up and the outputs are short-circuit
• DNL ±0.4 LSB (typ)
proof. The top and bottom of the ADC08200's
• ENOB (f
IN
= 50 MHz) 7.3 bits (typ)
reference ladder are available for connections,
• THD (f
IN
= 50 MHz) 61 dB (typ)
enabling a wide range of input possibilities. The
digital outputs are TTL/CMOS compatible with a
• Power Consumption
separate output power supply pin to support
– Operating 1.05 mW/Msps (typ)
interfacing with 3V or 2.5V logic. The digital inputs
– Power Down 1 mW (typ)
(CLK and PD) are TTL/CMOS compatible. The output
data format is straight binary.
APPLICATIONS
The ADC08200 is offered in a 24-lead TSSOP
• Flat Panel Displays
package and, while specified over the industrial
temperature range of −40°C to +85°C, it will function
• Projection Systems
over the to −40°C to +105°C temperature range.
• Set-Top Boxes
• Battery-Powered Instruments
• Communications
• Medical Imaging
• Astronomy
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2All trademarks are the property of their respective owners.
PRODUCTION DATA information is current as of publication date.
Copyright © 2001–2013, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
