Product/Process Change Notice - PCN 13_0241 Rev. -
Analog Devices, Inc. Three Technology Way Norwood, Massachusetts 02062-9106
This notice is to inform you of a change that will be made to certain ADI products (see Material Report). Any issues with this PCN or
requirements to qualify the change (additional data or samples) must be sent to ADI within 30 days of publication date. ADI contact
information is listed below.
PCN Title: Qualification of ASE Chungli as an Alternate Assembly Site for Select 16L, 20L and 24L
TSSOP Packages
Publication Date: 23-Jul-2014
Effectivity Date: 21-Oct-2014 (the earliest date that a customer could expect to receive changed material)
Revision Description:
Initial Release
Description Of Change
ADI has qualified and will be utilizing Assembly subcontractor ASE Chungli, Taiwan for TSSOP products in 16L, 20L and 24L package lead
counts. ADI has qualified ASE Chungli's standard bill of materials in the TSSOP package. See attached for BOM.
Reason For Change
The use of ADI qualified ASE Chungli as an additional assembly site for this package will ensure continued source of product supply. ADI's
assembly subcontractors manufacture our products using Analog Devices specified manufacturing flows, process controls and monitors.
This assures that our customers receive the same level of quality and reliability on products they receive from qualified ADI manufacturing
locations.
Impact of the change (positive or negative) on fit, form, function & reliability
There is no change in device functionality, fit, form and reliability. Only the country of origin will be changed on the package as marked on the
bottom side of the package with the mold tool mark or laser marked. Material used for the qualification are ADI previously qualified material
set.
Product Identification (this section will describe how to identify the changed material)
Devices assembled in ASE Chungli will have a tool mark or laser marking at the backside for the country of origin; in this case TAIWAN.
Summary of Supporting Information
Qualification has been performed per ADI0012, Procedure for Qualification of New or Revised Processes. See attached Qualification Report
Summary.
Supporting Documents
Attachment 1: Type: Qualification Results Summary
ADI_PCN_13_0241_Rev_-_Qualification Results Summary 20L_24L TSSOP ASE CHUNGLI.pdf
Attachment 2: Type: Detailed Change Description
Analog Devices, Inc. PCN 13_0241_Rev_- Page 1 of 4
