AP6502
Document Number: DS35423 Rev. 10 - 2
3 of 14
www.diodes.com
May 2017
© Diodes Incorporated
NEW PROD UC T
AP6502
Absolute Maximum Ratings (Note 4) (@T
A
= +25°C, unless otherwise specified.)
Symbol
Parameter
Rating
Unit
V
IN
Supply Voltage
-0.3 to +20
V
V
SW
Switch Node Voltage
-1.0 to V
IN
+0.3
V
V
BST
Bootstrap Voltage
V
SW
-0.3 to V
SW
+6
V
V
FB
Feedback Voltage
-0.3 to +6
V
V
EN
Enable/UVLO Voltage
-0.3 to +6
V
V
COMP
Comp Voltage
-0.3 to +6
V
T
ST
Storage Temperature
-65 to +150
°C
T
J
Junction Temperature
+150
°C
T
L
Lead Temperature
+260
°C
ESD Susceptibility (Note 5)
HBM
Human Body Model
3
kV
MM
Machine Model
250
V
Notes: 4. Stresses greater than the 'Absolute Maximum Ratings' specified above may cause permanent damage to the device. These are stress ratings only;
functional operation of the device at these or any other conditions exceeding those indicated in this specification is not implied. Device reliability
may be affected by exposure to absolute maximum rating conditions for extended periods of time.
5. Semiconductor devices are ESD sensitive and may be damaged by exposure to ESD events. Suitable ESD precautions should be taken when
handling and transporting these devices.
Thermal Resistance (Note 6) (@T
A
= +25°C, unless otherwise specified.)
Symbol
Parameter
Rating
Unit
θ
JA
Junction to Ambient
SO-8EP
74
°C/W
θ
JC
Junction to Case
SO-8EP
16
Note: 6. Test condition: SO-8EP: Device mounted on 1" x 1" FR-4 substrate PC board, 2oz copper, with minimum recommended pad on top layer and
thermal vias to bottom layer ground plane.
Recommended Operating Conditions (Note 7) (@T
A
= +25°C, unless otherwise specified.)
Symbol
Parameter
Min
Max
Unit
V
IN
Supply Voltage
4.7
18
V
T
A
Operating Ambient Temperature Range
-40
+85
°C
Note: 7. The device function is not guaranteed outside of the recommended operating conditions.
