Power 1 Form A (AQZ10❍, 20❍)
–2–
ASCTB150E 201404-T
RATING
1. DC type
1) Absolute maximum ratings (Ambient temperature: 25°C 77°F)
2) Electrical characteristics (Ambient temperature: 25°C 77°F)
Item Symbol AQZ102 AQZ105 AQZ107 AQZ104 Remarks
Input
LED forward current IF 50 mA
LED reverse voltage VR 5 V
Peak forward current IFP 1 A f = 100 Hz, Duty factor = 0.1%
Power dissipation Pin 75 mW
Output
Load voltage (DC) VL 60 V 100 V 200 V 400 V
Continuous load current (DC) IL 4.0 A 2.6 A 1.3 A 0.7 A
Peak load current Ipeak 9.0 A 6.0 A 3.0 A 1.5 A 100 ms (1 shot), VL = DC
Power dissipation Pout 1.35 W
Total power dissipation PT 1.35 W
I/O isolation voltage Viso 2,500 V AC
Temperature
limits
Operating T
opr –40°C to +85°C –40°F to +185°F Non-condensing at low temperatures
Storage Tstg –40°C to +100°C –40°F to +212°F
Item Symbol AQZ102 AQZ105 AQZ107 AQZ104 Condition
Input
LED operate current
Typical
I
Fon
1.0 mA
I
L= 100 mA
V
L= 10 V
Maximum 3.0 mA
LED turn off current
Minimum
I
Foff
0.4 mA
I
L= 100 mA
V
L= 10 V
Typical 0.9 mA
LED dropout voltage
Typical
V
F
1.25 V (1.16 V at IF = 10 mA)
IF = 50 mA
Maximum 1.5 V
Output
On resistance
Typical
R
on
0.05 Ω 0.081 Ω 0.34 Ω 1.06 Ω
I
F = 10 mA
I
L =Max.
Within 1 s on time
Maximum 0.09 Ω 0.17 Ω 0.55 Ω 1.6 Ω
Off state leakage current Maximum I
Leak 10 μA
I
F = 0 mA
V
L = Max.
Transfer
characteristics
Turn on time*
Typical
T
on
1.66 ms 1.89 ms 0.83 ms 1.01 ms
I
F = 10 mA
I
L = 100 mA
V
L = 10 V
Maximum 5.0 ms
Typical 3.79 ms 4.50 ms 1.75 ms 2.34 ms
I
F = 5 mA
I
L = 100 mA
V
L = 10 V
Maximum 10.0 ms
Turn off time*
Typical
T
off
0.15 ms 0.19 ms 0.08 ms 0.08 ms
I
F = 5 mA or 10 mA
I
L = 100 mA
V
L = 10 V
Maximum 3.0 ms
I/O capacitance
Typical
Ciso
0.8 pF
f = 1 MHz
V
B = 0 V
Maximum 1.5 pF
Initial I/O isolation resistance Minimum R
iso 1,000 MΩ 500 V DC
Maximum operating speed Maximum — 0.5 times/s
IF = 10 mA
Duty factor = 50%
I
L×VL= 200 (VA)
Vibration resistance Minimum — 10 to 55 Hz at double amplitude of 3 mm 2 hours for 3 axes
Shock resistance Minimum — 4,900 m/s
2
{500 G} 1 ms 3 times for 3 axes
