AT24C01C-SSHM-B数据手册
Page:
of 22 Go
若手册格式错乱，请下载阅览PDF原文件
Atmel-8700G-SEEPROM-AT24C01C-02C-Datasheet_012015
Features
Low-voltage Operation
V
CC
= 1.7V to 5.5V
Internally Organized as 128 x 8 (1K) or 256 x 8 (2K)
I
2
C Compatible (2-wire) Serial Interface
Schmitt Trigger, Filtered Inputs for Noise Suppression
Bidirectional Data Transfer Protocol
400kHz (1.7V) and 1MHz (2.5V, 2.7V, 5.0V) Compatibility
Write Protect Pin for Hardware Data Protection
8-byte Page Write Mode
Partial Page Writes Allowed
Self-timed Write Cycle (5ms max)
High-reliability
Endurance: 1,000,000 Write Cycles
Data Retention: 100 Years
Green Package Options (Pb/Halide-free/RoHS-compliant)
8-lead PDIP, 8-lead JEDEC SOIC, 8-lead TSSOP, 8-pad UDFN, 5-lead
SOT23, and 8-ball VFBGA
Die Sale Options: Wafer Form and Tape and Reel Available
Description
The Atmel
®
AT24C01C/02C provides 1024/2048-bits of Serial Electrically
Erasable and Programmable Read-Only Memory (EEPROM) organized as
128/256 words of eight bits each. Both devices include a cascading feature that
allows up to eight devices to share a common 2-wire bus. These devices are
optimized for use in many industrial and commercial applications where low
power and low voltage operation are essential. The AT24C01C/02C are available
in space saving 8-lead PDIP, 8-lead JEDEC SOIC, 8-lead TSSOP, 8-lead UDFN,
5-lead SOT23, and 8-ball VFBGA packages. In addition, the entire family
operates from 1.7V to 5.5V V
CC
.
AT24C01C and AT24C02C
I
2
C-Compatible (2-wire) Serial EEPROM
1-Kbit (128 x 8), 2-Kbit (256 x 8)
DATASHEET
