AT24C02D-SSHM-T数据手册
Page:
of 26 Go
若手册格式错乱，请下载阅览PDF原文件
Atmel-8871B-SEEPROM-AT24C01D-02D-Datasheet_032014
Features
Low voltage operation
1.7V (V
CC
= 1.7V to 3.6V)
Internally organized 128 x 8 (1K) or 256 x 8 (2K)
I
2
C-Compatible (2-wire) serial interface
Schmitt Triggers, filtered inputs for noise suppression
Bidirectional data transfer protocol
400kHz (1.7V) and 1MHz (2.5V) compatibility
Write Protect pin for full array hardware data protection
Ultra low active current (1mA max) and standby current (0.8μA max)
8-byte Page Write mode
Partial page writes allowed
Random and Sequential Read modes
Self-timed write cycle within 5ms max
High reliability
Endurance: 1,000,000 write cycles
Data retention: 100 years
Green package options (Lead-free/Halide-free/RoHS Compliant)
8-lead SOIC, 8-lead TSSOP, 8-pad UDFN, 8-lead PDIP,
(1)
5-lead SOT23, and
8-ball VFBGA
Die sale options: wafer form and tape and reel available
Description
The Atmel
®
AT24C01D/02D provides 1,024/2,048 bits of Serial Electrically
Erasable and Programmable Read-Only Memory (EEPROM) organized as
128/256 words of eight bits each. The device’s cascadable feature allows up to
eight devices to share a common 2-wire bus. These device are optimized for use
in many industrial and commercial applications where low-power and low-voltage
operation are essential. Both devices are available in space-saving 8-lead SOIC,
8-lead TSSOP, 8-pad UDFN, 8-lead PDIP,
(1)
5-lead SOT23, and
8-ball VFBGA packages. The entire family of packages operates from 1.7V to
3.6V.
Note: 1. Contact Atmel Sales for availability of this package.
AT24C01D and AT24C02D
I
2
C-Compatible (2-wire) Serial EEPROM
1-Kbit (128 x 8) or 2-Kbit (256 x 8)
DATASHEET
