Selecting the Best Serial EEPROM Interface
Protocol for your Application
1. Introduction
y Atmel offers Serial Electrically Erasable Programmable Read Only
Memories (SEEPROM) to designers wanting to save Printed Circuit Board
Assembly (PCBA) area and simplify hardware design. Serial refers to the
hardware interface scheme to write and read data from the device (two,
three, or four signals needed). The parallel interface scheme to write and
read data involves 18 or more signals. SEEPROM devices are 8 pin
packages compared to 20 or more pins on parallel interface EEPROM
devices. Since SEEPROMs have a smaller pin count than parallel
EEPROMS, the SEEPROM device packages are smaller and therefore
save PCBA area that would be consumed by the physically larger parallel
EEPROM devices. Since SEEPROMS have a smaller pin count on device
packages than parallel EEPROMS, there are fewer signals to route in the
PCBA design.
y When an SEEPROM solution is desired, more decisions are needed to
direct the designer to the best device for the application. The interface
protocol decision is quite often driven by hardware and software features of
the microcontroller that is to be interfaced to the SEEPROM. Atmel offers
three protocol families of SEEPROMs:
1. 2-Wire Interface (TWI) in the AT24CXXXX family [compatible
with I2C protocol]
2. 3-Wire Interface (3WI) in the AT93CXXX family
3. Serial Peripheral Interface (SPI) in the AT25XXXX family
y The following device features will be discussed should the designer have
the freedom to choose the interface protocol:
─ Interface signals
─ Chip Selection signal
─ Memory expansion
─ Maximum interface clock speeds
─ Command complexity
─ Write protection / data security
─ Cost
1.1. Interface Signals
TWI: a clock signal and a bi-directional data signal (SCL, SDA)
3WI: a clock signal, a data in signal, and a data out signal (SK, DI,
DO) [Chip Select is needed also]
SPI: a chip select signal, a clock signal, a data in signal, and a
data out signal (CS, SCK, SI, SO)
TWI fewest, 3WI and SPI have the same
8546A• SEEPR• 06/08
Serial EEPROM
Interface Protocol
Application Note
