8787B–SEEPR–5/12
Standard Features
Low-voltage and standard-voltage operation
V
CC
= 1.7V to 5.5V
Internally organized as 512 x 8 (4K), or 1024 x 8 (8K)
I
2
C-compatible (2-wire) serial interface
Schmitt Trigger, filtered inputs for noise suppression
Bidirectional data transfer protocol
1MHz (2.5V, 2.7V, 5V), 400kHz (1.7V) compatibility
Write Protect pin for hardware data protection
16-byte Page Write mode
Partial page writes allowed
Self-timed write cycle (5ms max)
High-reliability
Endurance: 1 million write cycles
Data retention: 100 years
Green package options (Pb/Halide-free/RoHS compliant)
8-lead PDIP, 8-lead SOIC, 8-lead TSSOP, 8-pad UDFN, 5-lead SOT23,
and 8-ball VFBGA
Die options: wafer form and tape and reel
Description
The Atmel
®
AT24C04C and AT24C08C provides 4096/8192 bits of Serial Electrically
Erasable and Programmable Read-Only Memory (EEPROM) organized as
512/1024 words of eight bits each. The device is optimized for use in many industrial
and commercial applications where low-power and low-voltage operation are essential.
AT24C04C/08C is available in space-saving 8-lead PDIP, 8-lead JEDEC SOIC,
8-lead TSSOP, 8-pad UDFN
, 5-lead SOT23, and 8-ball VFBGA packages and is
accessed via a 2-wire serial interface.
Atmel AT24C04C and Atmel AT24C08C
I
2
C-Compatible, (2-wire) Serial EEPROM
4-Kbit (512 x 8), 8-Kbit (1024 x 8)
DATASHEET
