Atmel-8568F-SEEPROM-AT24C256C-Datasheet_012015
Features
Low-voltage and Standard-voltage Operation
V
CC
= 1.7V to 5.5V
Internally Organized as 32,768 x 8
2-wire Serial Interface
Schmitt Trigger, Filtered Inputs for Noise Suppression
Bidirectional Data Transfer Protocol
400kHz (1.7V) and 1MHz (2.5V, 2.7V, 5.0V) Compatibility
Write Protect Pin for Hardware Protection
64-byte Page Write Mode
Partial Page Writes Allowed
Self-timed Write Cycle (5ms Max)
High Reliability
Endurance: 1,000,000 Write Cycles
Data Retention: 40 Years
Lead-free/Halogen-free Devices Available
Green Package Options (Pb/Halide-free/RoHS Compliant)
8-lead JEDEC SOIC, 8-lead TSSOP, 8-pad UDFN, and 8-ball VFBGA
Packages
Die Sale Options: Wafer Form, Waffle Pack, and Bumped Wafers
Description
The Atmel
®
AT24C256C provides 262,144-bits of Serial Electrically Erasable and
Programmable Read-Only Memory (EEPROM) organized as 32,768 words of
8 bits each. The device’s cascading feature allows up to eight devices to share a
common 2-wire bus. The device is optimized for use in many industrial and
commercial applications where low-power and low-voltage operation are
essential. The devices are available in space-saving 8-lead JEDEC SOIC, 8-lead
TSSOP, 8-pad UDFN, and 8-ball VFBGA packages. In addition, this device
operates from 1.7V to 5.5V.
AT24C256C
I
2
C-Compatible (2-Wire) Serial EEPROM
256-Kbit (32,768 x 8)
DATASHEET
