Atmel-3350G-SEEPROM-AT24C64B-Datasheet_012017
Features
Low-voltage and Standard-voltage Operation
2.7V (V
CC
= 2.7V to 5.5V)
1.8V (V
CC
= 1.8V to 5.5V)
Low-power Devices (I
SB
= 6μA at 5.5V) Available
Internally Organized 8192 x 8
2-Wire Serial Interface
Schmitt Trigger, Filtered Inputs for Noise Suppression
Bi-directional Data Transfer Protocol
400kHz Clock Rate
Write Protect Pin for Hardware Data Protection
32-byte Page Write Mode (Partial Page Writes Allowed)
Self-Timed Write Cycle (5ms max)
High Reliability
Endurance: 1,000,000 Write Cycles
Data Retention: 100 Years
Lead-free/Halogen-free Devices Available
8-lead JEDEC SOIC and TSSOP Packages
Description
The Atmel
®
AT24C64B provides 65,536 bits of Serial Electrically Erasable and
Programmable Read-Only Memory (EEPROM) organized as 8,192 words of 8 bits
each. The device’s cascadable feature allows up to eight devices to share a
common 2-Wire bus. The device is optimized for use in many industrial and
commercial applications where low-power and low-voltage operation are
essential. The AT24C64B is available in space saving 8-lead JEDEC SOIC and
8-lead TSSOP packages and is accessed via a 2-Wire serial interface. In addition,
the entire family is available in 2.7V (2.7 to 5.5V) and 1.8V (1.8 to 5.5V) versions.
AT24C64B
I
2
C-Compatible (2-Wire) Serial EEPROM
64K (8192 x 8)
DATASHEET
