AT89STK-06 Software Demonstration Guide 2-3
Rev. 4356C–CAN–07/05
Section 2
Getting Started
The purpose of this section is to acquaint the user with the Atmel CAN Demo Board, the
In-System Programming tool (FLIP), the 2 demonstration programs: CAN Generator
and CAN Monitor, and finally with the 2 bootloaders (CAN and UART).
2.1 Hardware
Requirements
CAN Demo board plus either a Second AT89STK-06
(1)
and/or a CAN Dongle
(1)
(IXXAT, PCAN, CANCARDX, CANPARI, or RMCANVIEW)
RS-232 Serial Cable (DB9/DB9 Male/Female)
Serial Cable DB9/DB9 Female/Female
(1)
AT89C51CC03U-SLIM or AT89C51CC03U-SLSIM
AT89C51CC03C-S3SIM
Notes: 1. Not included in CAN Demo Board kit.
2. The AT89STK-06 can also be used with T89C51CC01 and T89C51CC02
CAN controllers (requires optional adapter for T89C51CC02)
3. The AT89STK-06 can be used with AT89C51AC3, T89C51AC2, T89C5115
controllers with ADC (requires optional adapter for T89C5115).
2.2 Software
Requirements
Several demonstration programs can be found in the accompanying CD-ROM
CAN generator UART bootloader demonstration program (HEX file)
CAN monitor UART bootloader demonstration program (HEX file)
CAN generator CAN bootloader demonstration program (HEX file)
CAN monitor CAN bootloader demonstration program (HEX file)
CAN Dongle program (HEX file)
ADC demonstration program (HEX file)
(1)
A self training package is also available on the CAN CD-ROM. It introduces CAN bit
timing as welll as the CAN Software Library.
Note: 1. The ADC demo is the only demonstration program that can be used with non-
CAN products.
