2
SAM7X Series [DATASHEET]
6120K–ATARM–11-Feb-14
Features
Incorporates the ARM7TDMI ARM Thumb
®
Processor
High-performance 32-bit RISC Architecture
High-density 16-bit Instruction Set
Leader in MIPS/Watt
EmbeddedICE
™
In-circuit Emulation, Debug Communication Channel Support
Internal High-speed Flash
512 Kbytes (SAM7X512) Organized in Two Banks of 1024 Pages of
256 Bytes (Dual Plane)
256 Kbytes (SAM7X256) Organized in 1024 Pages of 256 Bytes (Single Plane)
128 Kbytes (SAM7X128) Organized in 512 Pages of 256 Bytes (Single Plane)
Single Cycle Access at Up to 30 MHz in Worst Case Conditions
Prefetch Buffer Optimizing Thumb Instruction Execution at Maximum Speed
Page Programming Time: 6 ms, Including Page Auto-erase,
Full Erase Time: 15 ms
10,000 Write Cycles, 10-year Data Retention Capability,
Sector Lock Capabilities, Flash Security Bit
Fast Flash Programming Interface for High Volume Production
Internal High-speed SRAM, Single-cycle Access at Maximum Speed
128 Kbytes (SAM7X512)
64 Kbytes (SAM7X256)
32 Kbytes (SAM7X128)
Memory Controller (MC)
Embedded Flash Controller, Abort Status and Misalignment Detection
Reset Controller (RSTC)
Based on Power-on Reset Cells and Low-power Factory-calibrated Brownout Detector
Provides External Reset Signal Shaping and Reset Source Status
Clock Generator (CKGR)
Low-power RC Oscillator, 3 to 20 MHz On-chip Oscillator and one PLL
Power Management Controller (PMC)
Power Optimization Capabilities, Including Slow Clock Mode (Down to 500 Hz) and Idle Mode
Four Programmable External Clock Signals
Advanced Interrupt Controller (AIC)
Individually Maskable, Eight-level Priority, Vectored Interrupt Sources
Two External Interrupt Sources and One Fast Interrupt Source, Spurious Interrupt Protected
Debug Unit (DBGU)
2-wire UART and Support for Debug Communication Channel interrupt, Programmable ICE Access Prevention
Mode for General Purpose 2-wire UART Serial Communication
Periodic Interval Timer (PIT)
20-bit Programmable Counter plus 12-bit Interval Counter
Windowed Watchdog (WDT)
12-bit key-protected Programmable Counter
Provides Reset or Interrupt Signals to the System
Counter May Be Stopped While the Processor is in Debug State or in Idle Mode
Real-time Timer (RTT)
32-bit Free-running Counter with Alarm
Runs Off the Internal RC Oscillator
Two Parallel Input/Output Controllers (PIO)
Sixty-two Programmable I/O Lines Multiplexed with up to Two Peripheral I/Os
Input Change Interrupt Capability on Each I/O Line
