All Prices are in US Dollars!
Toll-Free: 10800-1527031 (China Telecom -
፩࣭ݢᅹ
)
—
10800-8527031 (CNCG -
፩࣭၃
)
digikey.com.cn —
Telephone: (852) 3104 0500
—
Fax: (852) 3104 0686582
(CN081)
C
AVR
®
8-BIT RISC Microcontrollers
ATNGW100 Network Gateway Kit
The ATNGW100 is an ideal development board for the AT32AP7000. The ATNGW100 has two Ethernet
ports, SD and MMC card reader and connectors for USB and JTAG. The board is preloaded with Linux
®
and
shipped with I/O interface drivers that can be called from your own code.
ATNGW100-ND ............................................................................................. $89.00
ATSTK1000 Starter Kit
The ATSTK1000 provides a complete AT32AP7000 development environment. The kit comes with a pre-
installed Linux
®
image on a 256MB SD card. The ATSTK1000 has options that will help in development
such as, two ethernet ports, high quality QVGA LCD, a loudspeaker, PS/2, VGA, and an expansion header
for prototyping.
ATSTK1000-ND ...........................................................................................$532.00
ATEVK1100 Evaluation Kit
The ATEVK1100 is an evaluation kit and development system for the AVR32 AT32UC3A microcontroller. It
is equipped with a rich set of peripherals, memory, and makes it easy to try the full potential of the AVR32
devices.
ATEVK1100-ND ...........................................................................................$129.00
ATAVRMC100 BLDC Motor Control
The ATAVRMC100 BLDC motor control kit includes an evaluation board, a 3-phase BLDC motor and
demonstration software. Fully featured driver board for BLDC motors with hardware over-current detection.
Interface for sensor and sensorless BLDC, sensor and sensorless software included. Onboard AT90PWM3
AVR microcontroller. Header connectors for external driver inputs. Onboard LIN transceiver ATA6661.
ATAVRMC100-ND ........................................................................................ $211.47
ATAVRFBKIT Ballast Demo Kit
The ATAVRFBKIT is a Dimmable Fluorescent Ballast kit which is used to demonstrate the ability of the
AT90PWM2 to control all the main functions of a DALI Fluorescent Ballast. C code is provided to speed-up
development time.
ATAVRFBKIT-ND ........................................................................................ $211.47
ATAVRMC200 AC Induction Motor Control
The ATAVRMC200 is an evaluation kit dedicated to AC induction motor control. The kit includes an
evaluation board and demonstration software. It allows users to quickly evaluate the capability of the
AT90PWM3 AVR microcontroller to control a three phase asynchronous induction motor.
ATAVRMC200-ND ........................................................................................ $317.87
The AVR
®
ICE50 is a top-of-the-line development tool for complete in-circuit emulation of most AVR 8-bit
RISC microcontrollers. The ICE50 and the AVR Studio4 user interface give the user complete control of the
internal resources of the microcontroller, helping to reduce development time by making debugging easier.
ATICE50MEM-ND ICE50 Extension Memory Card ............................................ $246.05
ATICE50POD-ND Replacement POD for ICE40, ICE50 ...................................... $465.50
ATICE50PROBE-ND Probe with Flex Cables ......................................................$81.13
ATADAP128_TOP-ND TOP Adapter Module for ATmega64 ...................................... $199.50
ATADAP169_TOP-ND Personality Adapter for ATmega169 ...................................... $199.50
ATADAPMEGA8-ND Personality Adapter for ATmega8 ...........................................$41.23
ATADAPMEGA32-ND Personality Adapter for ATmega32 ..........................................$41.23
ATADAPMEGA162-ND Personality Adapter for ATmega162 ........................................$41.23
ATADAPT2313-ND Personality Adapter for ATtiny2313 .........................................$41.23
ATADAPTEST-ND ICE50 Adapter Test ..........................................................$41.23
ATADAPTINY13-ND Personality Adapter for ATtiny13 ............................................$41.23
ATADAPTINY26-ND Personality Adapter for ATtiny26 ............................................$41.23
ATSTK500 Starter Kit
The ATSTK500 is a starter kit and development system for Atmel's AVR flash microcontrollers. The
ATSTK500 gives designers a quick start to develop code on the AVR combined with features for using the
starter kit to develop prototypes and test new designs. The ATSTK500 interfaces with AVR Studio
®
, Atmel's
Integrated Development Environment (IDE) for code writing and debugging.
ATSTK500-ND ..............................................................................................$83.79
Emulator
Evaluation Kits
AVR
®
32 32-Bit Microcontroller
Digi-Key Price
Description Part No. Each
Module for STK501 ATSTK501-ND 83.79
Module for STK502 ATSTK502-ND 105.07
Module for STK503 ATSTK503-ND 125.02
Module for STK504 ATSTK504-ND 125.02
Module for STK505 ATSTK505-ND 83.79
Module for STK520 ATSTK520-ND 83.79
CAN Extension for STK500/501 ATADAPCAN01-ND 18.62
Starter Kit for AT90USB ATSTK525-ND 211.47
Starter Kit for AT90USB82/162 ATSTK526-ND 211.47
Digi-Key Price
Description Part No. Each
JTAGICE Emulator for AVR
®
2/OCD ATJTAGICE2-ND 317.87
Probe JTAGICE with Flex Cables ATJTAGPROBE-ND 41.23
Digi-Key Price
Description Part No. Each
Butterfly Evaluation Kit ATAVRBFLY-ND 21.28
Evaluation Kit for AT90USB AT90USBKEY-ND 31.92
USB Development Kits
Digi-Key Price
Description Part No. Each
IC USB HUB Controller, 4-Port, 32-LQFP AT43301-AU-ND◆ 1.98
IC USB HUB Controller, 4-Port, 24-SOIC AT43301-SU-ND◆ 1.83
IC USB HUB Controller, 4 Port, 32-LQFP AT43312A-AC-ND 2.02
IC USB Keyboard Controller Hub, 48-LQFP AT43USB326-AU-ND◆ 2.88
IC USB Keyboard Controller Hub, 64-LQFP AT43USB325E-AU-ND◆ 5.16
IC USB MCU W/H UB, ADC, PWM, 64-LQFP AT43USB355E-AU-ND◆ 6.36
USB Host/Function Development Kit for
AT43USB380 OTG/Host FunctionProcessor AT43DK380-PDC2-ND 1335.00
IC USB Processor, 64 LQFP AT43USB380E-AU-ND◆ 8.43
Development Kit for AT90CAN128 MCU ATDVK90CAN1-ND◆ 119.70
◆ RoHS Compliant
Adapters
NEW! ATEVK1101 Evaluation Kit
The ATEVK1101 is an evaluation kit and development system for the AVR32 AT32UC3B microcontroller. It
is equipped with a rich set of peripherals, memory, and makes it easy to try the full potential of the AVR32
devices.
ATEVK1101-ND ............................................................................................ $79.00
Programmer
Digi-Key Price
Description Part No. Each
ISP In-System Programmer ATAVRISP2-ND 35.91
AVR
®
Dragon
™
The AVR Dragon supports all programming modes for the AVR device family. The Dragon is also capable
of full emulation support for devices with 32KB or less flash memory. Firmware for the device is easily
upgraded using AVR Studio
®
to support new devices.
ATAVRDRAGON-ND .......................................................................................$51.87
Features: • Core Power Supply Voltage: 1.65V ~ 1.95V • I/O Power Supply Voltage: 3.0V ~ 3.6V
• Operating Temperature: -40°C ~ 85°C
SRAM Flash Cache I/O Ethernet Ext. Bus Frequency Digi-Key Price Each
MIPS (KBytes) (KBytes) (Inst/Data) Pins USB MAC 10/100 Interface UART Max. (MHz) Package Part No. 1 25 100
32 — 16KB/16KB 160 High-Speed 2 Yes 4 150 256-CTBGA AT32AP7000-CTUT-ND 21.82 16.14 14.42
210 32 — 16KB/16KB 90 High-Speed — Yes 4 150 208-LQFP AT32AP7001-ALUT-ND NEW! 19.14 10.89 10.68
32 — 16KB/16KB 85 High-Speed — Yes 4 150 196-CBGA AT32AP7002-CTUT-ND NEW! 18.49 11.43 11.14
32 128 — 109 Full-Speed + OTG 1 Yes 4 66 144-LQFP AT32UC3A0128-ALUT-ND NEW! 13.65 10.16 7.74
32 128 — 69 Full-Speed + OTG 1 No 4 66 100-TQFP AT32UC3A1128-AUT-ND NEW! 12.26 9.30 6.97
80
64 256 — 109 Full-Speed + OTG 1 Yes 4 66 144-LQFP AT32UC3A0256-ALUT-ND NEW! 15.59 11.60 8.85
64 256 — 69 Full-Speed + OTG 1 No 4 66 100-TQFP AT32UC3A1256-AUT-ND NEW! 14.30 10.64 8.11
64 512 — 109 Full-Speed + OTG 1 Yes 4 66 144-LQFP AT32UC3A0512-ALUT-ND NEW! 15.70 11.32 8.95
64 512 — 69 Full-Speed + OTG 1 No 4 66 100-TQFP AT32UC3A1512-AUT-ND NEW! 18.71 13.49 10.63
16 64 — 44 Full-Speed + OTG — — 3 60 64-TQFP AT32UC3B064-A2UT-ND NEW! 9.78 7.42 5.53
16 64 — 44 Full-Speed + OTG — — 3 60 64-QFN AT32UC3B064-Z2UT-ND NEW! 9.78 7.42 5.53
16 64 — 28 Full-Speed — — 2 60 48-TQFP AT32UC3B164-AUT-ND NEW! 9.03 6.85 5.10
16 64 — 28 Full-Speed — — 2 60 48-QFN AT32UC3B164-Z1UT-ND NEW! 9.03 6.85 5.10
32 128 — 44 Full-Speed + OTG — — 3 60 64-TQFP AT32UC3B0128-A2UT-ND NEW! 10.64 8.07 6.04
72
32 128 — 44 Full-Speed + OTG — — 3 60 64-QFN AT32UC3B0128-Z2UT-ND NEW! 10.64 8.07 6.04
32 128 — 28 Full-Speed — — 2 60 48-TQFP AT32UC3B1128-AUT-ND NEW! 9.89 7.50 5.61
32 128 — 28 Full-Speed — — 2 60 48-QFN AT32UC3B1128-Z1UT-ND NEW! 9.89 7.50 5.61
32 256 — 44 Full-Speed + OTG — — 3 60 64-TQFP AT32UC3B0256-A2UT-ND NEW! 12.26 9.30 6.97
32 256 — 44 Full-Speed + OTG — — 3 60 64-QFN AT32UC3B0256-Z2UT-ND NEW! 12.26 9.30 6.97
32 256 — 28 Full-Speed — — 2 60 48-TQFP AT32UC3B1256-AUT-ND NEW! 11.50 8.73 6.55
32 256 — 28 Full-Speed — — 2 60 48-QFN AT32UC3B1256-Z1UT-ND NEW! 11.50 8.73 6.55
