若手册格式错乱，请下载阅览PDF原文件
All prices are in U.S. dollars (www.digikey.com). —
Toll-Free: 00801-85-4023
Fax: (852) 3104 0686
—
Taiwan dollar available by credit card at www.digikey.tw.
552
(TW092-10)
C
The best combination of low-power consumption, 32-bit performance and 16-bit system cost. The AT91 series
provides the optimal combination of processing power, peripherals and memory blocks for demanding real-time
applications that require high performance on a tight power budget. Its wide range of Real Time Operating Systems and
sophisticated application development tools minimize the risk and time taken to bring new applications to the market.
Features: • 3-stage instruction execution pipeline for high instruction throughout • Single-cycle memory access through
EBI • Hardware multiplier-plus-barrel shifter gives DSP capability • PDC channels (on-chip DMA) free the processor for the
application • Advanced power management provides idle mode and disables unused peripherals • Low-latency Advanced
Interrupt Controller • Operating Temperature: Industrial -40°C ~ 85°C • Watchdog Timer
AT91 ARM
®
Thumb
®
Evaluation Kits
These kits are complete low-cost evaluation platforms, which enable real-time code development
and exploration of the AT91 ARM Thumb microcontrollers. The kits include: • Sample mi cro con trol-
ler • Evaluation Board with the Angel™ debug monitor • AT91 Getting Started CD-ROM with data
sheets and examples • DB9 serial cable • 2.1mm power jack (power supply not included) • Evalu-
ation copies of compilers and debuggers from Green Hills and ARM • SRAM • Flash • 2 Serial ports
• Reset button and con troller • Push buttons • LEDs • 20- pin JTAG ICE interface con nector • Volt -
age regulation • Clock generator • Board self-test program • Current con sumption measurement
capability • Expan sion slots for add-on cards with user specific memories and peripherals
AT91EB40A-ND Evaluation Kit for the AT91R40008 ........................................................ 200.00
AT91EB55-ND Evaluation Kit for the AT91M55800A ...................................................... 250.00
AT91EB42-ND Evaluation Kit for the AT91M42800A ...................................................... 250.00
AT91RM3400-DK-ND Development Kit for the AT91RM3400 ...................................................1950.00
AT91SAM7A1-EK-ND Evaluation Board for AT91SAM7A1 ........................................................ 600.00
AT91SAM7A2-EK-ND Evaluation Board for AT91SAM7A2 .......................................................1000.00
AT91SAM7A3-EK-ND Evaluation Board for AT91SAM7A3 ........................................................ 200.00
AT91SAM7L-STK-ND Evaluation Kit for ART91SAM7L — RoHS Compliant .................................. 100.00
AT91SAM7SE-EK-ND Evaluation Board for the AT91SAM7SE — RoHS Compliant ........................... 200.00
AT91SAM7S-EK-ND Evaluation Kit for AT91SAM7S ............................................................ 100.00
AT91SAM7X-EK-ND Evaluation Kit for AT91SAM7X256/128 .................................................... 200.00
AT91SAM9G20-EK-ND Evaluation Kit for AT91SAM9G20 — RoHS Compliant ................................. 500.00
AT91SAM9RL-EK-ND Evaluation Kit for AT91SAM9RL — RoHS Compliant .................................. 750.00
AT91SAM9XE-EK-ND Evaluation Kit for AT91SAM9XE — RoHS Compliant .................................. 500.00
AT91SAM9260-EK-ND Evaluation Kit for AT91SAM9260 — RoHS Compliant ................................. 500.00
AT91SAM9261-EK-ND Evaluation Kit for AT91SAM926EJ-S — RoHS Compliant ............................. 750.00
AT91SAM-ICE-ND Emulator for AT91 ARM7 / ARM9 ......................................................... 100.00
AT91SAM9263-EK-ND Evaluation Kit for AT91SAM9263 — RoHS Compliant ................................. 850.00
Program Memory Size Timer/ Clock
Memory Program RAM Boot ROM I/O Counters Speed VCC Digi-Key Price Each
Type Bytes Bytes Bytes Pins USART TWI SPI (16-bit) ADC DAC (MHz) (Core) Package Part No. 1 25 100
— — 8K — 32 2 — — 3 — — 40 1.8 ~ 3.6V 100-TQFP AT91M40800-33AU-ND 7.63 4.80 4.26
— — 8K — 54 2 — 2 6 — — 33 2.7 ~ 3.6V 144-LQFP AT91M42800A-33AU-ND 11.50 7.23 6.42
— — 8K — 58 3 — 1 6 8-ch/10-bit 2-ch/10-bit 33 2.7 ~ 3.6V 176-LQFP AT91M55800A-33AU-ND 14.08 8.85 7.86
— — 2K — 58 3 — 1 6 — — 25 2.7 ~ 3.6V 176-TQFP AT91M63200-25AU-ND 10.92 10.50 10.08
— — 256K — 32 2 — — 3 — — 75 1.65 ~ 1.95V 100-LQFP AT91R40008-66AU-ND 12.58 7.90 7.02
ROM 256K 96K — 63 4 1 1 6 — — 66 1.65 ~ 1.95V 100-LQFP AT91RM3400-AU-ND 15.48 12.00 10.80
ROM 32K 16K 128K 122 4 1 1 6 — — 180 1.65 ~ 1.95V 256-BGA AT91RM9200-CJ-002-ND 25.26 15.87 14.10
ROM 32K 16K 128K 122 4 1 1 6 — — 180 1.65 ~ 1.95V 208-PQFP AT91RM9200-QU-002-ND 23.76 14.92 13.26
— — 4K — 49 3 — 1 9 8-ch/10-bit — 40 3.0 ~ 3.6V 144-LQFP AT91SAM7A1-AU-ND 13.33 8.37 7.44
— — 16K — 57 2 — 1 10 16-ch/10-bit — 30 3.0 ~ 3.6V 176-LQFP AT91SAM7A2-AU-ND 10.99 10.57 10.14
Flash 256K 32K — 62 3 1 2 9 16-ch/10-bit — 60 3.0 ~ 3.6V 100-LQFP AT91SAM7A3-AU-ND 13.55 8.51 7.56
Flash 64K 6K — 80 2 1 1 1 4-ch/10-bit — 36 1.8 ~ 3.6V 128-LQFP AT91SAM7L64-AU-ND 9.35 5.88 5.22
Flash 64K 6K — 80 2 1 1 1 4-ch/10-bit — 36 1.8 ~ 3.6V 144-LFBGA AT91SAM7L64-CU-ND 10.97 6.89 6.12
Flash 128K 6K — 80 2 1 1 1 4-ch/10-bit — 36 1.8 ~ 3.6V 128-LQFP AT91SAM7L128-AU-ND 10.75 6.75 6.00
Flash 128K 6K — 80 2 1 1 1 4-ch/10-bit — 36 1.8 ~ 3.6V 144-LFBGA AT91SAM7L128-CU-ND 12.47 7.83 6.96
Flash 16K 4K — 21 1 1 1 1 8-ch/10-bit — 55 1.8 ~ 3.3V 48-QFN AT91SAM7S16-MU-ND 4.52 2.84 2.52
Flash 32K 8K — 21 1 1 1 2 8-ch/10-bit — 55 3.0 ~ 3.6V 48-LQFP AT91SAM7S32-AU001-ND 4.95 3.98 3.57
Flash 32K 8K — 32 2 1 1 3 8-ch/10-bit — 55 3.0 ~ 3.6V 64-LQFP AT91SAM7S321-AU-ND 5.59 3.51 3.12
Flash 32K 8K — 32 2 1 1 1 8-ch/10-bit — 55 1.8 ~ 3.3V 64-QFN AT91SAM7S321-MU-ND 5.91 3.72 3.30
Flash 512K 64K — 32 2 1 1 1 8-ch/10-bit — 55 1.8 ~ 3.3V 64-LQFP AT91SAM7S512-AU-ND 12.26 7.70 6.84
Flash 512K 64K — 32 2 1 1 1 8-ch/10-bit — 55 1.8 ~ 3.3V 64-QFN AT91SAM7S512-MU-ND 12.47 7.83 6.96
Flash 32K 8K — 88 2 1 1 1 8-ch/10-bit — 55 1.8 ~ 3.3V 128-LQFP AT91SAM7SE32-AU-ND 8.39 5.27 4.68
Flash 32K 8K — 88 2 1 1 1 8-ch/10-bit — 55 1.8 ~ 3.3V 144-LFBGA AT91SAM7SE32-CU-ND 10.00 6.28 5.58
Flash 64K 16K — 32 2 1 1 3 8-ch/10-bit — 55 3.0 ~ 3.6V 64-LQFP AT91SAM7S64-AU001-ND 6.99 5.53 4.88
Flash 128K 32K — 32 2 1 1 3 8-ch/10-bit — 55 3.0 ~ 3.6V 64-LQFP AT91SAM7S128AU001-ND 8.60 5.40 4.80
Flash 128K 32K — 32 2 1 1 3 8-ch/10-bit — 55 3.0 ~ 3.6V 64-QFN AT91SAM7S128-MU-ND 8.92 5.61 4.98
Flash 256K 64K — 32 2 1 1 3 8-ch/10-bit — 55 3.0 ~ 3.6V 64-LQFP AT91SAM7S256AU001-ND 10.32 6.48 5.76
Flash 256K 64K — 32 2 1 1 3 8-ch/10-bit — 55 3.0 ~ 3.6V 64-QFN AT91SAM7S256-MU-ND 10.64 6.69 5.94
Flash 256K 32K — 88 2 1 1 3 8-ch/10-bit — 48 3.0 ~ 3.6V 128-LQFP AT91SAM7SE256-AU-ND 12.26 7.70 6.84
Flash 256K 32K — 88 2 1 1 3 8-ch/10-bit — 48 3.0 ~ 3.6V 144-BGA AT91SAM7SE256-CU-ND 13.55 8.51 7.56
Flash 512K 32K — 88 2 1 1 3 8-ch/10-bit — 48 3.0 ~ 3.6V 128-LQFP AT91SAM7SE512-AU-ND 14.51 9.12 8.10
Flash 512K 32K — 88 2 1 1 3 8-ch/10-bit — 48 3.0 ~ 3.6V 144-BGA AT91SAM7SE512-CU-ND 15.59 9.79 8.70
Flash 128K 32K — 62 2 1 2 3 8-ch/10-bit — 55 3.0 ~ 3.6V 100-LQFP AT91SAM7X128-AU-ND 9.46 7.18 6.60
Flash 128K 32K — 62 2 1 2 1 8-ch/10-bit — 55 1.8 ~ 3.3V 100-TFBGA AT91SAM7X128-CU-ND 10.64 8.07 7.43
Flash 256K 64K — 62 2 1 2 3 8-ch/10-bit — 55 3.0 ~ 3.6V 100-LQFP AT91SAM7X256-AU-ND 11.40 8.64 7.69
Flash 256K 64K — 62 2 1 2 3 8-ch/10-bit — 55 3.0 ~ 3.6V 100-LQFP AT91SAM7X256-AU-999TR-ND 7419.96/1,000
Flash 256K 64K — 62 2 1 2 1 8-ch/10-bit — 55 1.8 ~ 3.3V 100-TFBGA AT91SAM7X256-CU-ND 12.47 9.46 8.41
Flash 512K 128K — 62 2 1 2 1 8-ch/10-bit — 55 1.8 ~ 3.3V 100-LQFP AT91SAM7X512-AU-ND 15.05 9.45 8.40
Flash 512K 128K — 62 2 1 2 1 8-ch/10-bit — 55 1.8 ~ 3.3V 100-TFBGA AT91SAM7X512-CU-ND 16.23 10.20 9.06
ROM 16K 8K 32K 96 4 1 2 6 4-ch/10-bit — 210 3.0 ~ 3.6V 208-PQFP AT91SAM9260-QU-ND 16.23 12.84 10.76
ROM 16K 8K 32K 96 4 1 2 6 4-ch/10-bit — 210 3.0 ~ 3.6V 217-BGA AT91SAM9260-CJ-ND 16.23 12.08 9.06
ROM 16K 8K 32K 96 4 1 2 2 4-ch/10-bit — 210 3.0 ~ 3.6V 217-LFBGA AT91SAM9260B-CU-ND 14.62 9.18 8.16
ROM 16K 8K 32K 96 4 1 2 2 4-ch/10-bit — 210 3.0 ~ 3.6V 208-PQFP AT91SAM9260B-QU-ND 14.62 9.18 8.16
ROM 32K 160K 32K 96 3 1 2 3 — — 240 3.0 ~ 3.6V 217-BGA AT91SAM9261-CJ-ND 11.44 11.00 10.56
ROM 32K 16K 32K 96 3 2 2 1 4-ch/10-bit — 210 3.0 ~ 3.6V 217-LFBGA AT91SAM9261SB-CU-ND 14.62 9.18 8.16
ROM 64K 32K — 96 4 1 2 2 4-ch/10-bit — 400 3.0 ~ 3.6V 217-LFBGA AT91SAM9G20-CU-ND 16.45 11.48 10.20
ROM 32K 64K — 118 4 2 1 1 6-ch/10-bit — 240 3.0 ~ 3.6V 144-LFBGA AT91SAM9R64-CU-ND 13.76 8.64 7.68
ROM 32K 64K — 118 4 2 1 3 6-ch/10-bit — 240 3.0 ~ 3.6V 217-LFBGA AT91SAM9RL64-CU-ND 16.13 10.13 9.00
Flash 128K 16K 32K 96 4 2 2 2 4-ch/10-bit — 240 1.65 ~ 1.95V 217-BGA AT91SAM9XE128-CU-ND 17.74 11.14 9.90
Flash 128K 16K 32K 96 4 2 2 2 4-ch/10-bit — 240 1.65 ~ 1.95V 208-PQFP AT91SAM9XE128-QU-ND 17.74 11.14 9.90
Flash 256K 32K 32K 96 4 2 2 2 4-ch/10-bit — 240 1.65 ~ 1.95V 217-BGA AT91SAM9XE256-CU-ND 19.14 12.02 10.68
Flash 256K 32K 32K 96 4 2 2 2 4-ch/10-bit — 240 1.65 ~ 1.95V 208-PQFP AT91SAM9XE256-QU-ND 19.14 12.02 10.68
Flash 512K 32K 32K 96 4 2 2 2 4-ch/10-bit — 240 1.65 ~ 1.95V 217-BGA AT91SAM9XE512-CU-ND 21.29 13.37 11.88
Flash 512K 32K 32K 96 4 2 2 2 4-ch/10-bit — 240 1.65 ~ 1.95V 208-PQFP AT91SAM9XE512-QU-ND 21.29 13.37 11.88
Flash 1024K 256K — 32 2 — — 3 3-ch/16-bit — 75 1.65 ~ 1.95V 121-BGA AT91FR40162SB-CU-ND 26.02 18.15 16.94
AT91 ARM
®
Thumb
®
Microcontrollers
