This is a summary document.
The complete document is
available on the Atmel website
at www.atmel.com.
11032BS–ATARM–09-Jul-13
Description
Based on the ARM926EJ-S™ core, the SAM9G25 is an embedded microprocessor
unit, running at 400 MHz and featuring connectivity peripherals, a high data bandwidth
architecture and a small footprint package option, making it an optimized solution for
industrial applications.
The multi-layer bus matrix is linked to 2 x 8 DMA channels as well as DMAs dedicated
to the communication and interface peripherals, ensuring uninterrupted data transfers
with minimal processor overhead. Interface peripherals include a camera interface that
supports direct connection to the ITU-R BT. 601/656 8-bit mode compliant sensors and
up to 12-bit grayscale sensors. Communication peripherals include a soft modem
supporting exclusively the Conexant SmartDAA line driver, HS (480 Mbps) USB Host
and Device ports with on-chip transceivers, FS USB Host, 10/100 Ethernet MAC, two
HS SDCard/SDIO/MMC interfaces, USARTs, SPIs, I2S, multiple TWIs and 10-bit ADC.
The External Bus Interface incorporates controllers offering support for 4-bank and 8-
bank DDR2/LPDDR, SDRAM/LPSDRAM, static memories, as well as specific circuitry
for MLC/SLC NAND Flash with integrated ECC up to 24 bits.
The SAM9G25 is available in a 217-ball BGA package with 0.8 mm ball pitch, as well
as in 247-ball TFBGA and 247-ball VFBGA packages with 0.5 mm ball pitch, making
it ideally suited for space-constrained applications.
AT91SAM ARM-based Embedded MPU
SAM9G25
SUMMARY DATASHEET
