ATMEGA1284-PU数据手册
Page:
of 672 Go
若手册格式错乱，请下载阅览PDF原文件
2020 Microchip Technology Inc. Data Sheet Complete DS40002070B-page 1
Features
High-performance, low-power 8-bit AVR
®
Microcontroller
Advanced RISC architecture
131 powerful Instructions – most single-clock cycle execution
32 × 8 general purpose working registers
Fully static operation
Up to 20MIPS throughput at 20MHz
On-chip 2-cycle multiplier
High endurance non-volatile memory segments
16/32/64/128KBytes of In-System Self-programmable Flash program memory
512/1K/2K/4KBytes EEPROM
1/2/4/16KBytes Internal SRAM
Write/Erase Cycles: 10,000 Flash/ 100,000 EEPROM
Data retention: 20 years at 85°C/ 100 years at 25°C
(1)
Optional Boot Code Section with Independent Lock Bits
In-System Programming by On-chip Boot Program
True Read-While-Write Operation
Programming Lock for Software Security
QTouch
®
Library Support
Capacitive touch buttons, sliders and wheels
QTouch and QMatrix™ acquisition
Up to 64 sense channels
JTAG (IEEE std. 1149.1 Compliant) Interface
Boundary-scan Capabilities According to the JTAG Standard
Extensive On-chip Debug Support
Programming of Flash, EEPROM, Fuses, and Lock Bits through the JTAG Interface
ATmega164A/PA/324A/PA/644A/PA/1284/P
megaAVR
®
Data Sheet
Introduction
The ATmega164A/PA/324A/PA/644A/PA/1284/P is a low power, CMOS 8-bit microcontrollers based on the
AVR
®
enhanced RISC architecture. The ATmega164A/PA/324A/PA/644A/PA/1284/P is a 40/49-pins device
ranging from 16 KB to 128 KB Flash, with 1 KB to 16 KB SRAM, 512 Bytes to 4 KB EEPROM. By executing
instructions in a single clock cycle, the devices achieve CPU throughput approaching one million instruc-
tions per second (MIPS) per megahertz, allowing the system designer to optimize power consumption ver-
sus processing speed.
