2
AVR506
8028C-AVR-02/07
2 General Porting Considerations
To make the porting process as easy as possible, we recommend to always refer to
registers and bit positions using their defined names, as absolute addresses and
values may change from device to device. When porting a design it is then often just
necessary to include the correct definition file. Some examples are shown below.
PORTE |= (1<<PORTE5); // Set pin 5 on port E high
DDR &= ~(1<<PORTE5); // Set pin 5 on port E as input
// Configure USI
USICR = (1<<USISIE)|(0<<USIOIE)|(1<<USIWM1)|(0<<USIWM0)|
(1<<USICS1)|(0<<USICS0)|(0<<USICLK)|(0<<USITC);
To avoid conflicts with added features and register functionality, never access
registers that are marked as reserved. Reserved bits should always be written to zero
if accessed. This ensures forward compatibility, and added features will stay in their
default states when unused.
3 Register and bit names
Between ATmega169 and ATmega169P some register bits has been added, but
none of the existing bits has been removed, nor moved to different locations.
In ATmega169 the USART module is named USART, while in ATmega169P it is
called USART0. This has consequences for all USART register and bit names, and
depending on the compiler used this might have consequences when porting the
code.
Table 3-1 shows the register names for ATmega169.
Table 3-1
. USART register names
ATmega169
Register name
Atmega169
Bit names
ATmega169P
Register name
ATmega169P
Bit names
RXB[7:0] RXB0[7:0]
UDR
TXB[7:0]
UDR0
TXB0[7:0]
RXC RXC0
TXC TXC0
UDRE UDRE0
FE FE0
DOR DOR0
UPE UPE0
U2X U2X0
UCSRA
MPCM
UCSR0A
MPCM0
RXCIE RXCIE0
TXCIE TXCIE0
UDRIEN UDRIEN0
RXEN RXEN0
TXEN TXEN0
UCSZ2 UCSZ02
UCSRB
RXB8
UCSR0B
RXB80
